Error ID Item Description
600501 Safety Circuit Activated
600502 Safety Circuit Activated Load Beam Power ON Out of Time Limit
600503 Safety Circuit Activated
600504 Safety Circuit Activated
600505 Safety Circuit Activated
610101 Nozzle Allocation No nozzle is specified in the current pattern program
data.
(Cause 1) The nozzles to be used in the current pattern program data are not prepared.
(Remedy 1) Set the nozzles for the production model in the nozzle stocker data and perform
the program change operation.
610102 Nozzle Allocation
610201 Recognition Internal Data XXXX
610301 Component Recognition Data
610302 Component Recognition Data
610401 Nozzle Replace Data No effective step exists in the current pattern pro-
gram when the nozzle change data is created.
610402 Nozzle Replace Data Adequate memory capacity was not left when the
nozzle change data was created.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
610403 Nozzle Replace Data Control Commands "-" were not specified for both
primary and secondary nozzles in the component
library data.
(Cause 1) The correct parameters are not set in the "Control command" text boxes of the
labels "Selected nozzle #1" and "Selected nozzle #2" in the component library data.
(Remedy 1) Set correct parameters.
3.3 Error IDs and Remedial Procedures
0308-003 2-99 AHB01ETRP
0308-002 2-99-1 AHB01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
610404 Nozzle Replace Data There is no nozzle to be used in the nozzle stocker
data.
(Cause 1) See the Description.
(Remedy 1) Set the nozzles to be used in the nozzle stocker data.
610405 Nozzle Replace Data Although the same type of nozzles are specified for
the pick-up priority and simulataneous pick-up steps,
only one nozzle exists.
(Cause 1) See the Description.
(Remedy 1)
Set two nozzles or more to be used for the "Simultaneous Pick-Up" and
"Pick-Up Priority" steps in the nozzle stocker data.
610406 Nozzle Replace Data All nozzle holder are bypass-specified.
610407 Nozzle Replace Data
610501 Internal Data The offset data (internal data) is replaced with unex-
pected data (value).
(Cause 1) See the Description.
(Remedy) Open the window for offset editing and save the data again.
610601 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Beam (X/Y)".
610602 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pu descent
dclr 1".
610603 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pu descent
dclr 2".
610604 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pu descent
dclr 2 stroke".
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
Error ID Item Description
610605 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pu ascent".
610606 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pl descent dclr
1".
610607 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pl descent dclr
2".
610608 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pl descent dclr
2 stroke".
610609 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pl ascent".
61060a Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Nozzle rota-
tion".
61060b Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Nozzle
change".
61060c Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Recognition
time".
61060d Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pu retention
time".
61060e Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Pl retention
time ".
61060f Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Mvbl recog
retention time".
610610 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Fxd recog
retention time".
610611 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Cmpnt detec-
tion (Sensor)".
610612 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Air blow".
610613 Cmpnt Library Data Error Error in "Contorol Data Select noz #1 Air blow off
timing".
610614 Cmpnt Library Data Error Error in "Contorol Data Select noz #2 Beam (X/Y)".
610615 Cmpnt Library Data Error Error in "Contorol Data Select noz #2 Pu descent
dclr 1".
610616 Cmpnt Library Data Error Error in "Contorol Data Select noz #2 Pu descent
dclr 2".
610617 Cmpnt Library Data Error Error in "Contorol Data Select noz #2 Pu descent
dclr 2 stroke".
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
