Error ID Item Description
63021e CPU2 Board H1 Mount Position Teach Task Timeout.
63021f CPU2 Board H1 Component Recognition Result Read Task
Timeout.
630220 CPU2 Board H2 P.E.C. Mark Task Timeout (Global, Image)
630221 CPU2 Board H2 P.E.C. Mark Task Timeout (Local)
630222 CPU2 Board H2 Nozzle Change Task Timeout.
630223 CPU2 Board H2 Nozzle Store Task Timeout.
630224 CPU2 Board H2 Nozzle Attach Task Timeout.
630225 CPU2 Board H2 Component Pick-Up Task Timeout.
630226 CPU2 Board H2 Recognition Image Taking Task Timeout. (Movable
Camera)
630227 CPU2 Board H2 Recognition Image Taking Task Timeout. (Fixed
Camera)
630228 CPU2 Board H2 V.Bend Detection Task Timeout.
630229 CPU2 Board H2 Component Mount Task Timeout.
63022a CPU2 Board H2 Component Abandonment Task Timeout.
63022b CPU2 Board H2 L Axis Up (Pass Line) Task Timeout.
63022c CPU2 Board H2 Checker Mark Recognition Task Timeout.
63022d CPU2 Board H2 Bad Marks Detection Timeout.
63022e CPU2 Board H2 Mount Position Teach Task Timeout.
63022f CPU2 Board H2 Component Recognition Result Read Task
Timeout.
630230 CPU2 Board
630231 CPU2 Board
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
0308-001 2-99-6 AHB01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
630301 Recognition Board
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
630401 HLSC2 Board
630403 HLSC2 Board System error occurred.
630501 EB005 Board EB005 Board was not detected.
630502 EB005 Board Flash write error.
630503 EB005 Board RAM read/write error.
630504 EB005 Board Flash write initialize error.
630505 EB005 Board Flash read/write error.
630506 EB005 Board Binary data error.
650301 Recognition Communication Error Refer to "Specifications of Recognition Error Codes".
650401 Component Library Data Error There is no camera available for recognition.
650501 Control-to-Control Commication Failure in Command Sending
650502 Control-to-Control Commication Lighting Control Board-to-Board Communication
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-001 2-99-7 AHB01ETRP
Error ID Item Description
660101 P.E.C. Inspection P.E.C. Mark #1 (Global)
660102 P.E.C. Inspection P.E.C. Mark #2 (Global)
660103 P.E.C. Inspection P.E.C. Mark #3 (Global)
660104 P.E.C. Inspection P.E.C. Mark #1 (Image)
660105 P.E.C. Inspection P.E.C. Mark #2 (Image)
660106 P.E.C. Inspection P.E.C. Mark #1 (Local)
660107 P.E.C. Inspection P.E.C. Mark #2 (Local)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
660201 P.E.C. Inspection Test P.E.C. Inspection was failed.
660301 P.E.C Light Teaching P.E.C. Light Teaching was failed.
660401 P.E.C. Inspection Others
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
670101 Component Recognition XXXX
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-003 2-100 AHB01ETRP
