Error ID Item Description
630301 Recognition Board
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
630401 HLSC2 Board
630403 HLSC2 Board System error occurred.
630501 EB005 Board EB005 Board was not detected.
630502 EB005 Board Flash write error.
630503 EB005 Board RAM read/write error.
630504 EB005 Board Flash write initialize error.
630505 EB005 Board Flash read/write error.
630506 EB005 Board Binary data error.
650301 Recognition Communication Error Refer to "Specifications of Recognition Error Codes".
650401 Component Library Data Error There is no camera available for recognition.
650501 Control-to-Control Commication Failure in Command Sending
650502 Control-to-Control Commication Lighting Control Board-to-Board Communication
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-001 2-99-7 AHB01ETRP
Error ID Item Description
660101 P.E.C. Inspection P.E.C. Mark #1 (Global)
660102 P.E.C. Inspection P.E.C. Mark #2 (Global)
660103 P.E.C. Inspection P.E.C. Mark #3 (Global)
660104 P.E.C. Inspection P.E.C. Mark #1 (Image)
660105 P.E.C. Inspection P.E.C. Mark #2 (Image)
660106 P.E.C. Inspection P.E.C. Mark #1 (Local)
660107 P.E.C. Inspection P.E.C. Mark #2 (Local)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
660201 P.E.C. Inspection Test P.E.C. Inspection was failed.
660301 P.E.C Light Teaching P.E.C. Light Teaching was failed.
660401 P.E.C. Inspection Others
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
670101 Component Recognition XXXX
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-003 2-100 AHB01ETRP
Error ID Item Description
680101 Comp. Missing (Sensor)
(Cause 1) The head vacuum sensor has detected "Component Missing".
Notes: (a) The same number of pick-up errors as specified in the component
library data (the parameter in the "1" text box of "Error process" in the
"Control Data" tab sheet) occurred continuously at the same feeder No.
(b) The sensor cannot detect a microcomponent or a component that has
rough surface and causes a lot of air leakage.
(Remedy 1) Follow the steps below to reset the machine to the normal condition.
(1) Press the [RETURN] button.
(2) Check the cause of the pick-up error and take correct measures.
• When a component shortage error has occurred, replenish components.
• When a component is not picked up correctly, remove the component.
(3) After taking the required countermeasures, re-start the production.
680201 Vacuum Sensor Error
(Cause 1) Although the recognition with the component recognition camera resulted in "OK",
the head vacuum sensor detected "Component Missing".
Notes: The same number of pick-up errors as specified in the component library
data (the parameter in the "1" text box of "Error process" in the "Control
Data" tab sheet) occurred continuously at the same feeder No.
(Remedy 1) Follow the steps below to reset the machine to the normal condition.
(1) Press the [RETURN] button.
(2) Check the cause of the pick-up error and take correct measures.
• When a component shortage error has occurred, replenish components.
• When a component is not picked up correctly, remove the component.
(3) After taking the required countermeasures, re-start the production.
680301 Comp. Missing (Recog)
(Cause 1) "Component Missing" was detected as the result of the recognition with the compo-
nent recognition camera.
Note: The same number of pick-up errors as specified in the component library
data (the parameter in the "2" text box of "Error process" in the "Control
Data" tab sheet) occurred continuously at the same feeder No.
(Remedy 1) Follow the steps below to reset the machine to the normal condition.
(1) Press the [RETURN] button.
(2) Check the cause of the pick-up error and take correct measures.
• When a component shortage error has occurred, replenish components.
• When a component is not picked up correctly, remove the component.
(3) After taking the required countermeasures, re-start the production.
3.3 Error IDs and Remedial Procedures
0206-002 2-101 AHB01ETRP
