0308-002 2-105-1 AHB01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
6b1001 V.Bend Detection System Error Syetem error. (1000)
6b1011 V.Bend Detection System Error Memory error in unit.(1010)
6b1061 V.Bend Detection System Error Laser error.(1060)
6b1071 V.Bend Detection System Error Memory error insensor section.(1070)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the machine and power it up again.
6b1081 V.Bend Detection System Error Sensor cable not connected. (1080)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the connection between the lead coplanarity unit PC and the sensor
head.
6b1091 V.Bend Detection System Error Unsteady mortor rotaion in sensor. (1090)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the connection of the power cable to the sensor head.
6b1101 V.Bend Detection System Error Laser OFF. (1100)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the machine and power it up again.
6b2001 V.Bend Detection Operation Error
6b2011 V.Bend Detection Operation Error Wrong level adjustment. (2010)
6b2031 V.Bend Detection Operation Error Wrong component no. (2030)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the machine and power it up again.
Error ID Item Description
6b2041 V.Bend Detection Operation Error Measurement Start Signal Not Recognized. (2040)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lead coplanarity unit PC and the cable connected to the main body.
(Measurement Start Signal)
6b2051 V.Bend Detection Operation Error Illegal Command Parameter. (2050)
6b2061 V.Bend Detection Operation Error Unknown Reference Component Data. (2060)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the machine and power it up again.
6b2071 V.Bend Detection Operation Error Improper Measurement Mode. (2070)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Make the measurement in the normal mode.
6b3001 V.Bend Detection Operation Error Coplanarity Error! (3000)
6b3011 V.Bend Detection Operation Error Terminal Misregistration Error! (3010)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
0308-002 2-105-2 AHB01ETRP
3.3 Error IDs and Remedial Procedures
0308-002 2-105-3 AHB01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
6b3021 V.Bend Detection Operation Error Terminal Detection Error! Wrong Measurement Data
(Completely Dark Image). (3020)
6b3031 V.Bend Detection Operation Error Terminal Detection Error! Error in Number of Ex-
tracted Terminals (labeling). (3030)
6b3041 V.Bend Detection Operation Error Terminal Detection Error! Terminal Allocation Error
(Impossible Terminal Arrangement Detection). (3040)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the component size and thickness data.
6b3061 V.Bend Detection Operation Error Terminal Detection Error! Edge Detection Error
(Impossible Edge Detection of Gauge during
Installation Calibration). (3060)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the pick-up condition of the calibration gauge and how the device is
mounted
6b3071 V.Bend Detection Operation Error Coplanarity Error! (3070)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
6b3081 V.Bend Detection Operation Error Impaired Terminal (Nicked) Error. (3080)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lead, ball position, and quantity data.
