0308-002 2-105-3 AHB01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
6b3021 V.Bend Detection Operation Error Terminal Detection Error! Wrong Measurement Data
(Completely Dark Image). (3020)
6b3031 V.Bend Detection Operation Error Terminal Detection Error! Error in Number of Ex-
tracted Terminals (labeling). (3030)
6b3041 V.Bend Detection Operation Error Terminal Detection Error! Terminal Allocation Error
(Impossible Terminal Arrangement Detection). (3040)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the component size and thickness data.
6b3061 V.Bend Detection Operation Error Terminal Detection Error! Edge Detection Error
(Impossible Edge Detection of Gauge during
Installation Calibration). (3060)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the pick-up condition of the calibration gauge and how the device is
mounted
6b3071 V.Bend Detection Operation Error Coplanarity Error! (3070)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
6b3081 V.Bend Detection Operation Error Impaired Terminal (Nicked) Error. (3080)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lead, ball position, and quantity data.
Error ID Item Description
6b3091 V.Bend Detection Operation Error 2pinTr Error! (ONE all NG)
6b30a1 V.Bend Detection Operation Error 2pinTr Error! (PIN1 upper)
6b30b1 V.Bend Detection Operation Error 2pinTr Error! (PIN1 lower)
6b30c1 V.Bend Detection Operation Error 2pinTr Error! (PIN2 upper)
6b30d1 V.Bend Detection Operation Error 2pinTr Error! (PIN2 lower)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
6b3101 V.Bend Detection Operation Error Reference Plane Flapping Error. (3100)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-002 2-105-4 AHB01ETRP
Error ID Item Description
6b3111 V.Bend Detection Operation Error Terminal Detection Error! Out of Edge Position
Measurable Range ("Near" Side). (3110)
6b3121 V.Bend Detection Operation Error Terminal Detection Error! Out of Edge Position
Measurable Range ("Far" Side). (3120)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) ) Check the component thickness and V-bend unit height offset data.
6b3131 V.Bend Detection Operation Error Sampling Error ("DARK" Alarm). (3130)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) ) Decrease the dark level (dlv) of the component library data.
6b3141 V.Bend Detection Operation Error Sampling Error ("BRIGHT" Alarm). (3140)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) ) Decrease the laser power (lpw) of the component library data.
6b9001 V.Bend Detection System Error Sysyem error. (9000)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the machine and power it up again.
6b9011 V.Bend Detection System Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-002 2-105-5 AHB01ETRP
