0206-003 2-106 AHB01ETRP
Error ID Item Description
6c0201 Not Ready
6c0202 Not Ready
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Make various preparations and turn on the [READY] button. After that, zero all
axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6c0301 Continuous Operation Impossible
6c0302 Continuous Operation Impossible
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6c0401 Internal Data Error
6c0402 Internal Data Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Press the [Cancel] button. After that, zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6c0501 Bar Code Model Change
6c0502 Bar Code Model Change
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
Error ID Item Description
6c0503 Bar Code Model Change
6c0504 Bar Code Model Change
6c0505 Bar Code Model Change
6c0506 Bar Code Model Change
6c0507 Bar Code Model Change
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6c0601 Conveyor Width Automatic Adjustment The PWC axis for conveyor width adjustment cannot
be driven. The L1 axis might be located lower than
the pass line.
6c0602 Conveyor Width Automatic Adjustment The PWC axis for conveyor width adjustment cannot
be driven. The L2 axis might be located lower than
the pass line.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6c0603 Conveyor Width Automatic Adjustment A P.C.B. exists on the L conveyor.
6c0604 Conveyor Width Automatic Adjustment A P.C.B. exists on the R conveyor.
6c0605 Conveyor Width Automatic Adjustment A P.C.B. exists on the R conveyor.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Remove the P.C.B. from the pertinent conveyor.
Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-003 2-107 AHB01ETRP
Error ID Item Description
6c0606 Conveyor Width Automatic Adjustment The PWC axis for conveyor width adjustment cannot
be driven. The L1 axis might be located lower than
the pass line.
6c0607 Conveyor Width Automatic Adjustment An error occurred in the PWC axis while the con-
veyor width was being changed.
6c0608 Conveyor Width Automatic Adjustment An error occurred in the PWC axis while the con-
veyor width was being changed.
6c0609 Conveyor Width Automatic Adjustment The PWC axis is not zeroed completely.
6c060a Conveyor Width Automatic Adjustment An error occurred in the PWC axis while the con-
veyor width was being changed through an smooth
inching operation.
6c060b Conveyor Width Automatic Adjustment The current position of the L1 axis is not managed
because the axis is not zeroed.
6c060c Conveyor Width Automatic Adjustment The current position of the L2 axis is not managed
because the axis is not zeroed.
6c060d Conveyor Width Automatic Adjustment The L1 axis was not zeroed successfully.
6c060e Conveyor Width Automatic Adjustment The L2 axis was not zeroed successfully.
6c060f Conveyor Width Automatic Adjustment The BPC axis was not zeroed successfully.
6c0610 Conveyor Width Automatic Adjustment The current position of the X1 axis is not managed
because the axis is not zeroed.
6c0611 Conveyor Width Automatic Adjustment The current position of the X2 axis is not managed
because the axis is not zeroed.
6c0612 Conveyor Width Automatic Adjustment The current position of the Y axis is not managed
because the axis is not zeroed.
6c0613 Conveyor Width Automatic Adjustment The escape operation of the X axis ended in an error
condition.
6c0614 Conveyor Width Automatic Adjustment The escape operation of the Y axis ended in an error
condition.
6c0615 Conveyor Width Automatic Adjustment The support pins could not ascend because the
maximum conveyor width was not obtained.
6c0616 Conveyor Width Automatic Adjustment The current P.C.B. width was not obtained because
the pattern program data is not defined.
6c0617 Conveyor Width Automatic Adjustment Software limit
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-004 2-108 AHB01ETRP
