Error ID Item Description
6c0606 Conveyor Width Automatic Adjustment The PWC axis for conveyor width adjustment cannot
be driven. The L1 axis might be located lower than
the pass line.
6c0607 Conveyor Width Automatic Adjustment An error occurred in the PWC axis while the con-
veyor width was being changed.
6c0608 Conveyor Width Automatic Adjustment An error occurred in the PWC axis while the con-
veyor width was being changed.
6c0609 Conveyor Width Automatic Adjustment The PWC axis is not zeroed completely.
6c060a Conveyor Width Automatic Adjustment An error occurred in the PWC axis while the con-
veyor width was being changed through an smooth
inching operation.
6c060b Conveyor Width Automatic Adjustment The current position of the L1 axis is not managed
because the axis is not zeroed.
6c060c Conveyor Width Automatic Adjustment The current position of the L2 axis is not managed
because the axis is not zeroed.
6c060d Conveyor Width Automatic Adjustment The L1 axis was not zeroed successfully.
6c060e Conveyor Width Automatic Adjustment The L2 axis was not zeroed successfully.
6c060f Conveyor Width Automatic Adjustment The BPC axis was not zeroed successfully.
6c0610 Conveyor Width Automatic Adjustment The current position of the X1 axis is not managed
because the axis is not zeroed.
6c0611 Conveyor Width Automatic Adjustment The current position of the X2 axis is not managed
because the axis is not zeroed.
6c0612 Conveyor Width Automatic Adjustment The current position of the Y axis is not managed
because the axis is not zeroed.
6c0613 Conveyor Width Automatic Adjustment The escape operation of the X axis ended in an error
condition.
6c0614 Conveyor Width Automatic Adjustment The escape operation of the Y axis ended in an error
condition.
6c0615 Conveyor Width Automatic Adjustment The support pins could not ascend because the
maximum conveyor width was not obtained.
6c0616 Conveyor Width Automatic Adjustment The current P.C.B. width was not obtained because
the pattern program data is not defined.
6c0617 Conveyor Width Automatic Adjustment Software limit
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-004 2-108 AHB01ETRP
Error ID Item Description
6c0701 Head Operation Error An error occurred during pick-up a component.
6c0702 Head Operation Error An error occurred during placeing a component.
6c0703 Head Operation Error
6c0704 Head Operation Error
6c0705 Head Operation Error
6c0706 Head Operation Error
6c0707 Head Operation Error
6c0801 NC-Axis Operation Error An logical error occurred for NC-axis.
6c0802 NC-Axis Operation Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-001 2-108-1 AHB01ETRP
Error ID Item Description
6d0101 P.E.C. Recognition Camera & Beam Recognition error occurred during teaching.
Offset
6d0102 P.E.C. Recognition Camera & Beam Checker mark not recognized on JIG P.C.B.
Offset
6d0103 P.E.C. Recognition Camera & Beam Checker mark not recognized on JIG P.C.B.
Offset
6d0104 P.E.C. Recognition Camera & Beam Checker mark not recognized on JIG P.C.B.
Offset
6d0105 P.E.C. Recognition Camera & Beam Checker mark not recognized on JIG P.C.B.
Offset
6d0201 Component Recognition Camera Recognition error occurred during teaching.
(Fixed) Magnification
6d0301 Component Recognition (Fixed) Recognition error occurred during teaching.
Camera Offset
6d0302 Component Recognition (Fixed) Recognition error occurred during teaching.
Camera Offset
6d0303 Component Recognition (Fixed) Recognition error occurred during teaching.
Camera Offset
6d0304 Component Recognition (Fixed) Recognition error occurred during teaching.
Camera Offset
6d0305 Component Recognition (Fixed) Recognition error occurred during teaching.
Camera Offset
6d0306 Component Recognition (Fixed) Recognition error occurred during teaching.
Camera Offset
6d0401 Head Rotational Center Offset JIG component not recognized through component
recognition camera.
6d0402 Head Rotational Center Offset JIG component not recognized through component
recognition camera.
6d0403 Head Rotational Center Offset JIG component not recognized through component
recognition camera.
6d0404 Head Rotational Center Offset JIG component not recognized through component
recognition camera.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-004 2-109 AHB01ETRP
