Error ID Item Description
6d0a01 Nozzle Stocker Position Offset Round mark not recognized.
6d0a02 Nozzle Stocker Position Offset Round mark not recognized.
6d0b01 Feeder Base Offset Round mark not recognized.
6d0b02 Feeder Base Offset Round mark not recognized.
6d0c01 Feeder (A) Offset Round mark not recognized.
6d0c02 Feeder (A) Offset Round mark not recognized.
6d0d01 Feeder (B) Offset Round mark not recognized.
6d0d02 Feeder (B) Offset Round mark not recognized.
6d0e01 Teaching Plate Offset Recognition error occurred during teaching.
6d0e02 Teaching Plate Offset
6d0f01 Teble Offset Checker mark not recognized on JIG P.C.B.
6d0f02 Teble Offset Checker mark not recognized on JIG P.C.B.
6d0f51 Teble Offset
6d0f52 Teble Offset
6d1001 Nozzle Center Offset Recognition error occurred during teaching.
6d1002 Nozzle Center Offset Recognition error occurred during teaching.
6d1003 Nozzle Center Offset
6d1010 Nozzle Center Offset Execute all zero operation.
6d1101 Traverse Offset Round mark not recognized.
6d1102 Traverse Offset Round mark not recognized.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-003 2-110 AHB01ETRP
Error ID Item Description
6d1201 Nozzle Stocker Offset Recognition error occurred during teaching.
6d1202 Nozzle Stocker Offset
6d1301 Nozzle Tip Position Offset Recognition error occurred during teaching.
6d1302 Nozzle Tip Position Offset
6d1401 Nozzle Height Offset Sensor is ON.
6d1402 Nozzle Height Offset Sensor is OFF. (1)
6d1403 Nozzle Height Offset Sensor is OFF. (2)
6d1501 Head Master Offset Sensor is ON.
6d1502 Head Master Offset Sensor is OFF. (1)
6d1503 Head Master Offset Sensor is OFF. (2)
6d1601 Lighting Teach Recognition error occurred during teaching.
6d1602 Lighting Teach Recognition error occurred during teaching.
6d1603 Lighting Teach EA05 nozzle not registered.
6d1f02 V.Bend Detection Unit Recognition error.
6d1f50 V.Bend Detection Unit Command send error.
6d1f51 V.Bend Detection Unit Command send error.
6d1f52 V.Bend Detection Unit Command send error.
6d1f53 V.Bend Detection Unit Command send error.
6d1f61 V.Bend Detection Unit Unit error reply.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-004 2- 11 1 AHB01ETRP
Error ID Item Description
6d1f62 V.Bend Detection Unit Reply time over.
6d1f63 V.Bend Detection Unit Command mismatch.
6d1f64 V.Bend Detection Unit Receive data error.
6d1f65 V.Bend Detection Unit Initial reply.
6d1f71 V.Bend Detection Unit Unit error reply.
6d1f72 V.Bend Detection Unit Reply time over.
6d1f73 V.Bend Detection Unit Command mismatch.
6d1f74 V.Bend Detection Unit Receive data error.
6d1f75 V.Bend Detection Unit Initial reply.
6d1f81 V.Bend Detection Unit Unit error reply.
6d1f82 V.Bend Detection Unit Reply time over.
6d1f83 V.Bend Detection Unit Command mismatch.
6d1f84 V.Bend Detection Unit Receive data error.
6d1f85 V.Bend Detection Unit Initial reply.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-002 2-111 -1 AHB01ETRP
