Error ID Item Description 6f1201 Tray 1 Pallet Returning No Pallet at Start of Returning Operation (Cause 1) Self-Diagnostics Error Message (Remedy 1) Check the condition of the pallet detection (BPH514). 6f1202 Tray 1 P…
Error ID Item Description
6f0201 Tray 1 Precheck Error
6f0202 Tray 1 Precheck Error
6f0203 Tray 1 Precheck Error
6f0204 Tray 1 Precheck Error
6f0205 Tray 1 Precheck Error
6f0206 Tray 1 Precheck Error
6f0207 Tray 1 Precheck Error
6f0601 Tray 1 Interlock
6f0602 Tray 1 Interlock
6f0603 Tray 1 Interlock
6f0604 Tray 1 Interlock
6f0605 Tray 1 Interlock
6f1001 Tray 1 Supply Operation Error
6f1002 Tray 1 Supply Operation Error Drawout Tray Step No. Mismatch (Returning)
6f1003 Tray 1 Supply Operation Error Drawout Tray Step No. Mismatch (Returning)
6f1004 Tray 1 Supply Operation Error Illegal Operation Mode (System)
6f1005 Tray 1 Supply Operation Error Indefinite TV-Axis Position
6f1101 Tray 1 Pallet Returning Elevator Moving Position Error
6f1102 Tray 1 Pallet Returning Elevator Operation Error
6f1103 Tray 1 Pallet Returning
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-1 AHB01ETRP
Error ID Item Description
6f1201 Tray 1 Pallet Returning No Pallet at Start of Returning Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
6f1202 Tray 1 Pallet Returning Prechecking Error
6f1203 Tray 1 Pallet Returning Traverse Operation Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6f1204 Tray 1 Pallet Returning No Pallet at Start and End of Returning Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection.
6f1205 Tray 1 Pallet Returning
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Remove the pallet being drawn out.
6f1206 Tray 1 Pallet Returning
6f1301 Tray 1 Pallet Drawout Error Elevator Drawout Level Movement Error (Before
Operation)
6f1302 Tray 1 Pallet Drawout Error Elevator Drawout Level Movement Error (During
Operation)
6f1303 Tray 1 Pallet Drawout Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-2 AHB01ETRP
Error ID Item Description
6f1401 Tray 1 Pallet Drawout Error No Pallet at Start of Drawout Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
6f1402 Tray 1 Pallet Drawout Error Traverse Chuck Position Movement Error (Before
Operation)
6f1403 Tray 1 Pallet Drawout Error Traverse Chuck Position Movement Error (During
Operation)
6f1404 Tray 1 Pallet Drawout Error Traverse Drawout Position Movement Error (Before
Operation)
6f1405 Tray 1 Pallet Drawout Error Traverse Drawout Position Movement Error (During
Operation)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6f1406 Tray 1 Pallet Drawout Error No Pallet at End of Drawout Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
6f1407 Tray 1 Pallet Drawout Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallets in the magazine. (Oblique Insertion, etc.)
6f1408 Tray 1 Pallet Drawout Error
6f1501 Tray 1 Elevator Change Position Change Position Movement Error (Before
Movement Error Operation)
6f1502 Tray 1 Elevator Change Position Change Position Movement Error (During
Movement Error Operation)
6f1503 Tray 1 Elevator Change Position
Movement Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-3 AHB01ETRP
