Error ID Item Description
6f1401 Tray 1 Pallet Drawout Error No Pallet at Start of Drawout Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
6f1402 Tray 1 Pallet Drawout Error Traverse Chuck Position Movement Error (Before
Operation)
6f1403 Tray 1 Pallet Drawout Error Traverse Chuck Position Movement Error (During
Operation)
6f1404 Tray 1 Pallet Drawout Error Traverse Drawout Position Movement Error (Before
Operation)
6f1405 Tray 1 Pallet Drawout Error Traverse Drawout Position Movement Error (During
Operation)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6f1406 Tray 1 Pallet Drawout Error No Pallet at End of Drawout Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
6f1407 Tray 1 Pallet Drawout Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallets in the magazine. (Oblique Insertion, etc.)
6f1408 Tray 1 Pallet Drawout Error
6f1501 Tray 1 Elevator Change Position Change Position Movement Error (Before
Movement Error Operation)
6f1502 Tray 1 Elevator Change Position Change Position Movement Error (During
Movement Error Operation)
6f1503 Tray 1 Elevator Change Position
Movement Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-3 AHB01ETRP
Error ID Item Description
6f1601 Tray 1 Feeder Zeroing Error The rack shutter did not open within the specified
time. (0101)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensors BPS501 and BPS503.
6f1602 Tray 1 Feeder Zeroing Error The pallet chuck did not close within the specified
time. (0201)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPS512.
6f1603 Tray 1 Feeder Zeroing Error A pallet was detected with the pallet not being drawn
out. (0202)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
6f1604 Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (0203)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6f1605 Tray 1 Feeder Zeroing Error An ejected pallet wad detected with the pallet not
being drawn out. (0301)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
6f1606 Tray 1 Feeder Zeroing Error The traverse was not zeroed completely within the
specified time. (0302)
6f1607 Tray 1 Feeder Zeroing Error The traverse was not zeroed completely within the
specified time. (0303)
6f1608 Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (0401)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0206-001 2-1 13-4 AHB01ETRP
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-5 AHB01ETRP
Error ID Item Description
6f1609 Tray 1 Feeder Zeroing Error A pallet was not detected although it was drawn out.
(0402)
6f160a Tray 1 Feeder Zeroing Error A pallet was not detected although it was drawn out.
(0403)
6f160b Tray 1 Feeder Zeroing Error The pallet wad not detected. The drawout log was
cleared. (BPH514) (0501)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet and remove the pallet.
6f160c Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (0601)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6f160d Tray 1 Feeder Zeroing Error The pallet was not detected. Sensor Error! (BPH514)
(0701)
6f160e Tray 1 Feeder Zeroing Error The pallet was not detected within the specified time.
(0702)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet.
6f160f Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (0901)
6f1610 Tray 1 Feeder Zeroing Error The chuck did not open within the specified time.
(1001)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6f1611 Tray 1 Feeder Zeroing Error Failed in the setting of driving waves. (1101)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPS511.
3.3 Error IDs and Remedial Procedures
