0206-001 2-1 13-8 AHB01ETRP Error ID Item Description 6f1625 Tray 1 Feeder Zeroing Error The rack shutter did not close within the specified time. (2301) (Cause 1) Self-Diagnostics Error Message (Remedy 1) Check Sensors …
0206-001 2-1 13-7 AHB01ETRP
Error ID Item Description
6f161b Tray 1 Feeder Zeroing Error The chuck did not close within the specified time.
(1602)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPS512.
6f161c Tray 1 Feeder Zeroing Error The rack shutter did not close within the specified
time. (1701)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensors BPS502 and BPH504.
6f161d Tray 1 Feeder Zeroing Error The zeroing operation of the traverse ended in an
error condition. (0304)
6f161e Tray 1 Feeder Zeroing Error The zeroing operation of the traverse ended in an
error condition. (1801)
6f161f Tray 1 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L1 axis was not located at its origin.
(2000)
6f1620 Tray 1 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L2 axis was not located at its origin.
(2001)
6f1621 Tray 1 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L1 axis was not located at its origin.
(2100)
6f1622 Tray 1 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L2 axis was not located at its origin.
(2101)
6f1623 Tray 1 Feeder Zeroing Error A tray was detected at the return position. (1503)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6f1624 Tray 1 Feeder Zeroing Error The chuck did not close within the specified time.
(2201)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPS512.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-8 AHB01ETRP
Error ID Item Description
6f1625 Tray 1 Feeder Zeroing Error The rack shutter did not close within the specified
time. (2301)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensors BPS502 and BPS504.
6f1626 Tray 1 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (2401)
6f1627 Tray 1 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (2501)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
6f1628 Tray 1 Feeder Zeroing Error Defective Pallet Detection Sensor (BPH514) (1603)
6f1629 Tray 1 Feeder Zeroing Error Defective Pallet Detection Sensor (BPH514) (2601)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPH514.
6f162a Tray 1 Feeder Zeroing Error The zeroing operation of the elevator ended in an
error condition. (2701)
6f162b Tray 1 Feeder Zeroing Error The zeroing operation of the elevator ended in an
error condition. (2801)
6f162c Tray 1 Feeder Zeroing Error The zeroing operation of the elevator ended in an
error condition. (2901)
6f162d Tray 1 Feeder Zeroing Error Origin Not Detected by Sensor (3001)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
Error ID Item Description
6f162e Tray 1 Feeder Zeroing Error
6f162f Tray 1 Feeder Zeroing Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Remove the mispicked component on the tray.
6f1701 Tray 1 Feeder Zeroing Error A palllet was detected at the elevator origin.
(BPH514) (5001)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPH514.
6f1901 Tray 1 Feeder Zeroing Error The L1 axis might be located lower than the pass
line.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) ) Zero the L1 axis.
6f1902 Tray 1 Feeder Zeroing Error The L2 axis might be located lower than the pass
line.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero the L2 axis.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-9 AHB01ETRP
