Error ID Item Description
701605 Tray 2 Feeder Zeroing Error An ejected pallet wad detected with the pallet not
being drawn out. (0301)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
701606 Tray 2 Feeder Zeroing Error The traverse was not zeroed completely within the
specified time. (0302)
701607 Tray 2 Feeder Zeroing Error The traverse was not zeroed completely within the
specified time. (0303)
701608 Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (0401)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
701609 Tray 2 Feeder Zeroing Error A pallet was not detected although it was drawn out.
(0402)
70160a Tray 2 Feeder Zeroing Error A pallet was not detected although it was drawn out.
(0403)
70160b Tray 2 Feeder Zeroing Error The pallet wad not detected. The drawout log was
cleared. (BPH514) (0501)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet and remove the pallet.
70160c Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (0601)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
70160d Tray 2 Feeder Zeroing Error The pallet was not detected. Sensor Error! (BPH514)
(0701)
70160e Tray 2 Feeder Zeroing Error The pallet was not detected within the specified time.
(0702)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-15 AHB01ETRP
Error ID Item Description
70160f Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (0901)
701610 Tray 2 Feeder Zeroing Error The chuck did not open within the specified time.
(1001)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
701611 Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (1101)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPS511.
701613 Tray 2 Feeder Zeroing Error An ejected pallet was detected. (1202)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensors BPH504 and BPH505.
701614 Tray 2 Feeder Zeroing Error The pallet was not detected. (1203)
701615 Tray 2 Feeder Zeroing Error The elevator could not move to the return step
becaue the pallet was not drawn out. (1301)
701616 Tray 2 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (1302)
701617 Tray 2 Feeder Zeroing Error The elevator movement to the return step ended in an
error condition. (1401)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
701618 Tray 2 Feeder Zeroing Error The rack shutter did not open within the specified
time. (1501)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensors BPS501 and BPS503.
0206-001 2-1 13-16 AHB01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
701619 Tray 2 Feeder Zeroing Error The chuck did not open within the specified time.
(1502)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPS511.
70161a Tray 2 Feeder Zeroing Error The rack shutter did not close within the specified
time. (1601)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensors BPS502 and BPS504.
70161b Tray 2 Feeder Zeroing Error The chuck did not close within the specified time.
(1602)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPS512.
70161c Tray 2 Feeder Zeroing Error The rack shutter did not close within the specified
time. (1701)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensors BPS502 and BPS504.
70161d Tray 2 Feeder Zeroing Error The zeroing operation of the traverse ended in an
error condition. (0304)
70161e Tray 2 Feeder Zeroing Error The zeroing operation of the traverse ended in an
error condition. (1801)
70161f Tray 2 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L1 axis was not located at its origin.
(2000)
701620 Tray 2 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L2 axis was not located at its origin.
(2001)
701621 Tray 2 Feeder Zeroing Error The zeroing operation could not be performed be-
cause the L1 axis was not located at its origin.
(2100)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-17 AHB01ETRP
