Error ID Item Description
760301 P Conveyor Error BPC-Axis was not readyed. (3110, 1)
760302 P Conveyor Error P.C.B was taken on Output Conveyor. (3110, 2)
760303 P Conveyor Error BPC-Axis was not readyed. (3110, 3)
760304 P Conveyor Error BPC-Axis was not readyed. (3110, 4)
760401 P Conveyor Error Stopper cylinder action was not completed within
specified time. (3115, 1)
760402 P Conveyor Error BPC-Axis error was detected. (3115, 2)
760403 P Conveyor Error P.C.B. removed from conveyor. (3115, 3)
760404 P Conveyor Error P.C.B. removed from conveyor. (3115, 4)
760405 P Conveyor Error P.C.B was taken on Output Conveyor. (3115, 5)
760406 P Conveyor Error BPC-Axis was not readyed. (3115, 6)
760501 P Conveyor Error BPC-Axis error was detected. (3116, 1)
760502 P Conveyor Error BPC-Axis was not readyed. (3116, 2)
760601 P Conveyor Error Stopper cylinder action was not completed within
specified time. (3119, 1)
760602 P Conveyor Error BPC-Axis error was detected. (3119, 2)
760701 P Conveyor Error P.C.B. removed from conveyor. (3150, 1)
760801 P Conveyor Error BPC-Axis error was detected. (3151,1)
760901 P Conveyor Error BPC-Axis error was detected. (3153, 1)
760902 P Conveyor Error P.C.B. removed from conveyor. (3153, 2)
760a01 P Conveyor Error P.C.B was taken on Output Conveyor. (3120, 1)
760a02 P Conveyor Error BPC-Axis error was detected. (3120, 2)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Remove the improper P.C.B. on the conveyor. After that, zero all axes and re-
start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-003 2-116 AHB01ETRP
Error ID Item Description
760a03 P Conveyor Error P.C.B. removed from conveyor. (3120, 3)
760b01 P Conveyor Error BPC-Axis was not readyed. (3121, 1)
760c01 P Conveyor Error Stopper cylinder action was not completed within
specified time. (3123, 1)
760c02 P Conveyor Error P.C.B. removed from conveyor. (3123, 2)
760c03 P Conveyor Error P.C.B was taken on Output Conveyor. (3123, 3)
760d01 P Conveyor Error Output conveyor error was detected. (3124, 1)
760d02 P Conveyor Error BPC-Axis was not readyed. (3124, 2)
760e01 P Conveyor Error The stopper cylinder did not stop working within the
specified time. (3128, 1)
760e02 P Conveyor Error BPC-Axis error was detected. (3128, 2)
760e03 P Conveyor Error Conveyor motor error was detected. (3128, 3)
760f01 P Conveyor Error Not conforming to the requirements for the test
mode. (3190, 1)
761001 P Conveyor Error Not conforming to the requirements for the test
mode. (3191, 1)
761101 P Conveyor Error Input conveyor error was detected. (3210, 1)
761102 P Conveyor Error P.C.B. xfr from Inp cnvr were discontinued before
P.C.B. reached act completed. (3210, 2)
761103 P Conveyor Error P.C.B. transfer was not completed by a set time.
(3210, 3)
761104 P Conveyor Error P.C.B was taken on Output Conveyor. (3210, 4)
761105 P Conveyor Error P.C.B was taken on Output Conveyor. (3210, 5)
761106 P Conveyor Error P.C.B was taken on Output Conveyor. (3210, 6)
761201 P Conveyor Error P.C.B. xfr from Inp cnvr were discontinued before
P.C.B. reached act completed. (3212, 1)
761202 P Conveyor Error P.C.B was taken on Output Conveyor. (3212, 2)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-003 2-117 AHB01ETRP
Error ID Item Description
761301 P Conveyor Error P.C.B. xfr from Inp cnvr were discontinued before
P.C.B. reached act completed.(3215, 1)
761302 P Conveyor Error P.C.B was taken on Output Conveyor. (3215, 2)
761303 P Conveyor Error P.C.B. transfer was not completed by a set time.
(3215, 3)
761401 P Conveyor Error P.C.B was taken on Output Conveyor. (3216, 1)
761402 P Conveyor Error P.C.B. xfr from Inp cnvr were discontinued before
P.C.B. reached act completed. (3216, 2)
761403 P Conveyor Error P.C.B. transfer was not completed by a set time.
(3216, 3)
761501 P Conveyor Error P.C.B. xfr from Inp cnvr were discontinued before
P.C.B. reached act completed. (3217, 1)
761502 P Conveyor Error P.C.B. transfer was not completed by a set time.
(3217, 2)
761601 P Conveyor Error P.C.B was taken on Output Conveyor. (3218, 1)
761701 P Conveyor Error BPC-Axis error was detected. (3122, 1)
761801 P Conveyor Error BPC-Axis error was detected. (3117, 1)
761802 P Conveyor Error P.C.B. removed from conveyor. (3117, 2)
761803 P Conveyor Error P.C.B. removed from conveyor. (3117, 3)
761901 P Conveyor Error P.C.B. stopper at inlet of conveyor was not upper
position. (3113, 1)
762001 P Conveyor Error P.C.B was taken on Output Conveyor. (3291, 1)
762101 P Conveyor Error P.C.B was taken on Output Conveyor. (3295, 1)
762201 P Conveyor Error P.C.B. transfer was not completed by a set time.
(3310, 1)
761b01 P Conveyor Error Input conveyor error was detected. (3205, 1)
761b02 P Conveyor Error P.C.B. transfer was not completed by a set time.
(3205, 2)
761c01 P Conveyor Error P.C.B. transfer was not completed by a set time.
(3211, 1)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-004 2-118 AHB01ETRP
