3.3 Error IDs and Remedial Procedures Error ID Item Description ff0616 Interlock Interrupt Beam Power Shut-off (Cause 1) Self-Diagnostics Error Message (Remedy 1) Zero all axes and re-start the operation. When the machin…
Error ID Item Description
ff0601 Interlock Interrupt Beam Power Shut-off
ff0602 Interlock Interrupt Air pressure is too low.
ff0603 Interlock Interrupt Emergency stop detection
ff0604 Interlock Interrupt Front safety door was opened.
ff0605 Interlock Interrupt Rear safety door was opened.
ff0606 Interlock Interrupt CB Alarm
ff0607 Interlock Interrupt Safety Circuit
ff0608 Interlock Interrupt Load Power Shut-off
ff0609 Interlock Interrupt FAN Alarm #1
ff060a Interlock Interrupt FAN Alarm #2
ff060b Interlock Interrupt Safety Door (Front or Rear Unknown)
ff060c Interlock Interrupt Y-Axis Servo Ready Shut-off Detection
ff060d Interlock Interrupt X-Axis Servo Ready Shut-off Detection
ff060e Interlock Interrupt Safety Bar Front Detection
ff060f Interlock Interrupt Safety Bar Rear Detection
ff0610 Interlock Interrupt Safety Bar Detection (Front or Rear Unknown)
ff0611 Interlock Interrupt Beam Step-Out Detection 1
ff0612 Interlock Interrupt Beam Step-Out Detection 2
ff0613 Interlock Interrupt Beam Step-Out Detection (1 or 2 Unknown)
ff0614 Interlock Interrupt Tray Main Body I/F Interlock
ff0615 Interlock Interrupt Tray Main Body I/F Interlock
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-003 2-121 AHB01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
ff0616 Interlock Interrupt Beam Power Shut-off
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0308-002 2-121-1 AHB01ETRP
4. Troubleshooting after "ERROR" Window (Recogni-
tion Error ID)
4.1 Typical Description
Table 4B7
Recognition Error ID Item Description
02 ** 1000 ** Component Missing Component was not found.
(Cause 1) The feeders may be loaded with components different from the specified
ones.
(Cause 2) The vacuum suction force is too weak.
(Cause 2) An improper nozzle is selected for the components or vice versa.
(Remedy 1) Check if proper components are used.
(Remedy 2) Check the vacuum pressure.
(Remedy 3) Check the parameters in the nozzle type data and the component library
data.
02 ** 2101 ** Error in Outward Length Inspection Component Outward Length X is incorrect.
(Cause 1)
(Remedy 1)
(Continue to next page. )
*1 The recognition error IDs (IDs displayed in the "ERROR" window)
are described in the numerical order.
*2 Described are the error name (item) and the description in the "ER-
ROR" window.
*3 Described are the causes and remedial procedures of the errors
(Item and Description).
The causes and remedies are correlated as follows.
(Cause 1) Æ (Remedy 1)
(Cause 2) Æ (Remedy 2)
(Cause 3) Æ (Remedy 3)
*4 This indicates that the related contents are described subsequently
on the next page.
*1 *2 *3
*2
*4
4. Troubleshooting after "ERROR" Window (Recognition Error ID)
0206-003 2-122 AHB01ETRP
