Basic System of Recognition Error IDs
A recognition error ID is expressed by 10 digits (decimal number) as
follows.
AA BB C DDDDD
Detailed Classification : Detail Code based on
Classification of Rec-
ognition Functions
Error Classification : Secondary Classifi-
cation Code of De-
tailed Classification
Error Classification : Primary Classifica-
tion Code of Detailed
Classification
Classification of Recognition Functions
Classification of Recognition Functions
Table 4B8
Recognition Error IDs Classification of Recognition Functions
01 Recognition Communication and Data
Check
02 Component Recognition Function
03 P.E.C. Recognition Function
04 Nozzle Recognition Function
05 Character Recognition Function
10 Various Teaching Functions
14 Lighting Control Board-to-Board Communi-
cation
4.2 Recognition Error IDs and Controlled Areas
0206-002 2-123 AHB01ETRP
4.3 Recognition Error IDs and Remedial Procedures
4.3.1 Recognition Communication and Data Errors
AA BB C DDDDD
Detail Code
Secondary Error Classification
1: Recognition Communication
Data Range Error
2: Input Data Assembly Error
3: Input Data Error
Primary Error Classification
10 to 70: Communication Commands
90: Communication Procedure
91: Command Error
92: Response Error
Classification (01) of Recognition Functions
When an error ID other than the described ones is issued, con-
tact our service personnel for some advice.
Table 4B9
Error ID Item Description
01 ** 1***** Error in Recognition Communication Data -----
(Cause 1) An error was found in the recognition communication data.
(Remedy 1) Contact our service personnel for details.
01 14 3 00000 "Lighing for Ceramic P.C.B." is not Connected! -----
(Cause 1) Failed in confirmation to the connection of the lighting unit for ceramic
boards.
(Remedy 1) Contact our service personnel for some advice.
4.3 Recognition Error IDs and Remedial Procedures
0206-002 2-124 AHB01ETRP
Error ID Item Description
01 30 2 00000 The transferred magnification does not meet the -----
specifications of the machine.
(Cause 1) The magnification exceeding the specified one was transferred.
(Remedy 1) Contact our service personnel for details.
01 30 3 00001 Error in "Camera MAGNIFICATION X or
MAGNIFICATION Y" Data.
(Cause 1) Wrong parameters are set.
(Remedy 1) Set correct parameters.
01 38 2 00000 Unavailable fiducial mark code was set.
01 38 2 00001 "Mark Size D2" is too big, compared with "D1".
01 38 2 00002 "Mark Size D3" is too big, compared with "D1".
01 38 2 00003 "Mark Size D2" is too big, comapred with "D3".
01 38 2 00004 "Window Size" is smaller than "Mark Size".
01 38 2 00005 "Mark Size D2" is not set.
01 38 2 00006 "Mark Size D3" is not set.
01 38 3 00001 Error in "P.C.B Recognition Mark Data MarkSize
D1 or D2 or D3" Data.
01 38 3 00003 Error in "P.C.B Recognition Mark Data Window
Size" Data.
(Cause 1) Wrong parameters are set for the P.E.C. recognition function.
(Remedy 1) Refer to "Section 2 Pattern Program" in "Vol. 3" for details and set cor-
rect parameters.
0206-002 2-125 AHB01ETRP
