Error ID Item Description 01 63 2 00000 The specified error image is not saved. ----- 01 64 1 00000 A-E Data is incorrect ----- 01 65 1 00000 Device Code or T ype Code is incorrect ----- 01 66 1 00000 Initialization mode…

Error ID Item Description

01 58 1 00010 Pickup pos correction X is incorrect -----

01 58 1 00011 Pickup pos correction Y is incorrect -----

01 58 1 00012 Start Mode is incorrect -----

01 60 1 00000 Implement Recognition Mode is incorrect -----

01 61 1 00000 Display Mode is incorrect -----

01 61 1 00001 Component Recognition Setting is incorrect -----

01 61 1 00002 Cam No. is incorrect -----

01 61 1 00003 Component ID is incorrect -----

01 61 1 00004 Fdr.No. is incorrect -----

01 61 1 00005 Dsiplay Mode is incorrect -----

01 62 1 00000 Save Operation is incorrect -----

01 62 1 00001 Save Function is incorrect -----

01 62 1 00002 Reognition Save Mode is incorrect -----

01 62 1 00003 Component Recog Setting is incorrect -----

01 62 1 00004 Cam No. is incorrect -----

01 62 1 00005 Component ID is incorrect -----

01 62 1 00006 Fdr.No. is incorrect -----

01 62 1 00007 Resolution of Saved Image is incorrect -----

01 63 1 00000 Saved Image ID is incorrect -----

4.3 Recognition Error IDs and Remedial Procedures

0308-001 2-139-2 AHB01ETRP

Error ID Item Description

01 63 2 00000 The specified error image is not saved. -----

01 64 1 00000 A-E Data is incorrect -----

01 65 1 00000 Device Code or Type Code is incorrect -----

01 66 1 00000 Initialization mode is incorrect -----

01 90 0 00000 Recognition Communication Procedure Error -----

01 91 0 00000 Recognition Communication Error -----

01 92 0 00000 Recognition Communication Error -----

01 93 0 00000 Recognition Communication Error -----

(Cause 1) Self-Diagnostics Error Message

(Remedy 1) Contact our service personnel for details.

4.3 Recognition Error IDs and Remedial Procedures

0308-001 2-139-3 AHB01ETRP

4.3.2 Component Recognition Errors

AA BB C DDD EE

Detail Code : Kinds of Errors (00 to 99)

Detail Code : Kinds of Errors (000 to 999)

Secondary Error Classification:

Error Classification (1 to 99)

Primary Error Classification:

Recognition Algorithm (00 to

99)

Refer to Table 4B10.

Classification of Recognition Functions (02)

Error Classification: Recognition Algorithm

Table 4B10

BB Recognition Algorithm Remarks

00 Others

01 Edge (Rectangle) Front Lighting

02 Corner Back Lighting

03 Corner Front Lighting

04 Edge (General Purpose) Back Lighting

05 Edge (General Purpose) Front Lighting

06 Center of Gravity (Angle Detected) Back Lighting

07 Center of Gravity (Angle Detected) Front Lighting

08 Center of Gravity (Angle Not Detected) Back Lighting

09 Center of Gravity (Angle Not Detected) Front Lighting

10 Line Back Lighting

11 Line Front Lighting

31 Leaded Back Lighting

32 Leaded Front Lighting

33 Multiple Pin Leads (Standard) Back Lighting

34 Multiple Pin Leads (Standard) Front Lighting

35 Multiple Pin Leads (General Purpose) Back Lighting

36 Multiple Pin Leads (General Purpose) Front Lighting

37 Lead (Special) Back Lighting

38 Lead (Special) Front Lighting

39 Lead (Standard 2) Front Lighting

40 Multi-Pin Lead (Standard 2) Back Lighting

41 Multi-Pin Lead (Standard 2) Front Lighting

91 Grid Pattern Front Lighting

92 Grid Pattern Front Lighting

93 Grid Pattern (Divided) Front Lighting

94 Grid Pattern (Divided) Front Lighting
