Error ID Item Description
02 ** 3400 ** Error in Line Detection
02 ** 3401 ** Error in Line Detection Some linear edges cannot be detected they are
hidden by the nozzle.
02 ** 3402 ** Error in Line Detection No Linear Edge Detected.
02 ** 3403 ** Error in Line Detection The Deteted Linear Edge Position Does Not The
Position Data.
02 ** 3500 ** Error in Lead Detection
02 ** 3501 ** Error in Lead Detection Some leads cannot be detected because they are
hidden by the nozzle.
02 ** 3502 ** Error in Lead Detection No Lead Detected.
02 ** 3503 ** Error in Lead Detection Corner of Leads Not Detected.
02 ** 3504 ** Error in Lead Detection Ends of Leads Not Detected.
02 ** 3505 ** Error in Lead Detection Ends of Arrayed Leads Not Detected.
02 ** 3506 ** Error in Lead Detection Lead Edges of Corner Not Detected.
02 ** 3507 ** Error in Lead Detection Leads of Corner Not Detected.
02 ** 3508 ** Error in Lead Detection The number of leads at the detected corner is
smaller than the set value.
02 ** 3509 ** Error in Lead Detection Incorrect Lead-to-Lead Distance at Detected Cor-
ner.
02 ** 3510 ** Error in Lead Detection Incorrect Lead-to-Lead Angle at Detected Corner.
02 ** 3512 ** Error in Lead Detection The detected number of leads is smaller than the
set value.
02 ** 3513 ** Error in Lead Detection The detected number of leads is larger than the
set value.
02 ** 3514 ** Error in Lead Detection Incorrect Detected Group-to-Group Distance.
02 ** 3515 ** Error in Lead Detection The Detected Lead Position Does Not Match the
Position Data.
(Cause 1) The results of the lead detection differ from the parameters specified in the
component library data for the selected components.
(Remedy 1) Check the leads of the selected component and the component library
data.
If wrong parameters are set in the component library data, correct them.
4.3 Recognition Error IDs and Remedial Procedures
0308-003 2-145 AHB01ETRP
Error ID Item Description
02 ** 3600 ** Error in Electrode (Ball) Detection.
02 ** 3601 ** Error in Electrode (Ball) Detection. No Electrode (Ball) Detected.
02 ** 3602 ** Error in Electrode (Ball) Detection. Since a sufficient number of Electrode (Ball) were
undetectable, it cannot position.
02 ** 3603 ** Error in Electrode (Ball) Detection. There is Electrode (Ball) undetectable in the line or
sequence ofa group outside.
02 ** 3604 ** Error in Electrode (Ball) Detection. Electrode (Ball) which is in agreement with data
was undetectable.
02 ** 3605 ** Error in Electrode (Ball) Detection. Electrode (Ball) which is not specified was de-
tected.
(Cause 1) The results of the lead detection differ from the parameters specified in the
component library data for the selected components.
(Remedy 1) Check the leads of the selected component and the component library
data.
If wrong parameters are set in the component library data, correct them.
02 ** 4200 ** Error in Pick-up Position Detection.
02 ** 4201 ** Error in Pick-up Position Detection. The pick-up position has deviated greatly in X di-
rection.
02 ** 4202 ** Error in Pick-up Position Detection. The pick-up position has deviated greatly in Y di-
rection.
02 ** 4203 ** Error in Pick-up Position Detection. The pick angular skew is big.
(Cause 1) The results of the lead detection differ from the parameters specified in the
component library data for the selected components.
(Remedy 1) Check the leads of the selected component and the component library
data.
If wrong parameters are set in the component library data, correct them.
4.3 Recognition Error IDs and Remedial Procedures
0308-004 2-146 AHB01ETRP
Error ID Item Description
02 ** 8000 ** Data Error
02 ** 8001 ** Data Error Data Error in Process.
02 ** 8002 ** Data Error Error in Lighting Data.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
02 ** 9000 ** Other Errors
02 ** 9001 ** Other Errors Internal Processing Error.
02 ** 9002 ** Other Errors Impossible to set the detection window.
02 ** 9003 ** Other Errors Impossible to set the window for arrayed lead end
detection.
02 ** 9004 ** Other Errors Impossible to set the window for lead detection at
the corner.
02 ** 9005 ** Other Errors Impossible to set the window for lead detection.
02 ** 9006 ** Other Errors Angle Calculation Impossible.
02 ** 9007 ** Other Errors Internal Processing Error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
4.3 Recognition Error IDs and Remedial Procedures
0308-001 2-146-1 AHB01ETRP
