Error ID Item Description
10 57 0 00000 ---- Result was out of tolerance.
10 57 0 00001 ---- Nozzle outward was out of tolerance.
10 57 0 00002 ---- The teaching operation did not end within the speci-
fied number of time.
10 57 0 00003 ---- Brightness exceeds the range of tuning.
10 57 0 010** ---- The lamp (right side) for the P.E.C. recognition did
not illuminate.
10 57 0 011** ---- The lamp (left side) for P.E.C. recognition did not
illuminate.
10 57 0 0120* ---- The lamp for back lighting in the movable lighting
system (right side) did not illuminate.
10 57 0 0121* ---- The upper lamp for front lighting in the movable light-
ing system (right side) did not illuminate.
10 57 0 0122* ---- The middle lamp for front lighting in the movable
lighting system (right side) did not illuminate.
10 57 0 0123* ---- The lower lamp for front lighting in the movable light-
ing system (right side) did not illuminate.
10 57 0 0130* ---- The lamp for back lighting in the movable lighting
system (left side) did not illuminate.
10 57 0 0131* ---- The upper lamp for front lighting in the movable light-
ing system (left side) did not illuminate.
10 57 0 0132* ---- The middle lamp for front lighting in the movable
lighting system (left side) did not illuminate.
10 57 0 0133* ---- The lower lamp for front lighting in the movable light-
ing system (left side) did not illuminate.
10 57 0 0140* ---- The lamp for back lighting in the fixed lighting sys-
tem (Side A) did not illuminate.
10 57 0 0141* ---- The upper lamp for front lighting in the fixed light-
ing system (Side A) did not illuminate.
10 57 0 0142* ---- The middle lamp for front lighting in the fixed light-
ing system (Side A) did not illuminate.
10 57 0 0143* ---- The lower lamp for front lighting in the fixed lighting
system (Side A) did not illuminate.
(Cause 1) An error occurred during the teaching operation of the lighting.
(Remedy 1) Contact our service personnel for details.
0206-002 2-151 AHB01ETRP
4.3 Recognition Error IDs and Remedial Procedures
Error ID Item Description
10 57 0 0150* ---- The lamp for back lighting in the fixed lighting sys-
tem (Side B) did not illuminate.
10 57 0 0151* ---- The upper lamp for front lighting in the fixed light-
ing system (Side B) did not illuminate.
10 57 0 0152* ---- The middle lamp for front lighting in the fixed light-
ing system (Side B) did not illuminate.
10 57 0 0153* ---- The lower lamp for front lighting in the fixed lighting
system (Side B) did not illuminate.
10 57 0 016** ---- The lamp for back light stage did not illuminate.
(Cause 1) An error occurred during the teaching operation of the lighting.
(Remedy 1) Contact our service personnel for details.
4.3 Recognition Error IDs and Remedial Procedures
0206-001 2-152 AHB01ETRP
4.3.6 Lighting Control Board-to-Board Communication Errors
AA BB C DDDDD
Detail Code
Secondary Error Classification (0)
Primary Error Classification (0)
Classification of Recognition Functions (14)
When an error ID other than the described ones is issued, con-
tact our service personnel for some advice.
Table 4B16
Error ID Item Description
14 00 0 00000 ---- Other Errors in Communication between Lighting
Control Boards!
14 00 0 00001 ---- Error in Communication between Recognition
and Lighting Control Boards!
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
4.3 Recognition Error IDs and Remedial Procedures
