1.3 Machine Information

1.3.1 "Machine Information" Window

••

• Window Layout

Various machine information is displayed while the machine is run-

ning.

While the "Machine Information" window is active, the machine

keeps on running.

Fig. 4B2-1 Example of "Machine Information"

••

• Window Composition

*1 Machine Information

The machine information is displayed.

Refer to "1.3.2 List of Check Messages" for details.

1.3 Machine lnformation

0308-001 2-3-7 AHB01ETRP

*2 Display Section A

Displayed is the outline of the machine information.

*3 Display Section B

Displayed are the details of the machine information.

*4 [OK] Button

When pressed, this button closes the "Machine Information" win-

dow.

*5 [Clear Alarm] Button

When pressed, this button cancels an alarm (sound) only.

1.3 Machine lnformation

0308-001 2-3-8 AHB01ETRP

1.3.2 List of Check Messages

Table 4B1-7

Error ID Display Section A Display Section B

800501 Alarm for Shortage Few components to feed.

of Component

800601 Shortage of Compo- Few components to feed.

nent (Tray Step)

(Contents) Self-Diagnostics Error Message

(Description) The automatic operation will stop soon due to component shortage.

Prepare for component replenishment.

800701 Product Information Finished Product Interval :

800702 Product Information Auto Run Interval :

800703 Product Information Nozzle Usage Interval :

800801 Machine Interface No signal from furnace.

Signal

800901 Machine Interface

Signal

800a01 Operate Information

800b01 Automatic Feeder

Axis adjustment

limit soft

(Contents) Self-Diagnostics Error Message

(Description) Confirm the displayed contents.

800c01 Alarm for

Maintenance

(Contents) Self-Diagnostics Error Message

(Description) Follow the displayed instructions for maintenance work.

1.3 Machine lnformation
