Key No. PART No. PART NAME Q'ty REMARKS REGISTERED No. 1 616 121 6991 FILTER REGULATOR 1 648BE-11H-501 1CC2BC5400160 2 616 111 7748 COCK 1 648BE-11H-511 1CC2BE0500010 3 616 123 8610 ELBOW 1 1CC2BD1000810 4 616 123 8…
Key No. PART No. PART NAME Q'ty REMARKS REGISTERED No.
1 616 121 6991 FILTER REGULATOR 1 648BE-11H-501 1CC2BC5400160
2 616 111 7748 COCK 1 648BE-11H-511 1CC2BE0500010
3 616 123 8610 ELBOW 1 1CC2BD1000810
4 616 123 8634 TEE 1 1CC2BD4500010
5 616 123 8627 NIPPLE 2 1CC2BD3500120
6 616 111 7786 PRESSURE SWITCH 1 648BE-11H-502 1CC2BC5600010
7 616 111 7830 AIR BUSHING 1 648BE-11H-532 1CC2BD5500070
8 616 111 7847 ELBOW 1 648BE-11H-519 1CC2BD1000140
9 616 111 7854 ELBOW 3 648BE-11H-528 1CC2BD1000150
10 616 111 7878 BRANCH 1 648BE-11H-520 1CC2BD6000030
11 616 111 7861 PLUG 1 648BE-11H-521 1CC2BD4000040
12 616 123 8641 UNION 1 1CC2BD5000340
13 616 121 7141 UNION 1 1CC2BD5000180
16 411 141 4503 WASHER V 8X17X1.6 2 FW8
17 411 141 3100 WASHER SPR 8 2 SW8
18 630 000 7985 BOLT,HEX-SCT 2 M8X10
20 616 121 7080 SOLENOID VALVE ASSY 1 648BE-11H-515 1CC4L83002460
21 616 123 8689 ELBOW 3 1CC2BD1000390
22 616 122 0363 ELBOW 2 648BE-11H-545 1CC2BD1000173
22 -1 616 125 8519 ELBOW 2 648BE-11H-546 1CC2BD1001560
23 411 141 4008 WASHER V 4X9X0.8 4 FW4
24 411 141 2905 WASHER SPR 4 4 SW4
25 630 000 7688 BOLT,HEX-SCT 4 M4X30
26 616 121 7042 CLEANER 1 648BE-11H-509 1CC2BC1400051
27 616 123 8610 ELBOW 1 1CC2BD1000810
28 616 121 7158 BRANCH 1 648BE-11H-526 1CC2BD6000140
29 616 121 7165 AIR JOINT 1 648BE-11H-527 1CC2BD0500350
31 616 121 7066 COCK 1 648BE-11H-512 1CC2BE0500070
32 616 123 8696 AIR JOINT 1 1CC2BD0500101
33 411 141 4305 WASHER V 6X12.5X1.6 2 FW6
34 411 141 3001 WASHER SPR 6 2 SW6
35 630 000 7862 BOLT,HEX-SCT 2 M6X10
36 616 121 7103 PLUG 1 648BE-11H-518 1CC2BD4000060
NOTE
10-2
9703-001
MODEL TIM-1000L
