Key No. PART No. PART NAME Q'ty REMARKS REGISTERED No.
57 616 121 3501 TERMINAL FUSE 1 648GB-11D-510 1CC4S30500020
58 616 900 0011 FUSE 125V 1A 1 648GB-11D-513 F51S1R0A1FGNB
59 616 121 3501 TERMINAL FUSE 4 648GB-11D-510 1CC4S30500020
60 616 900 0035 FUSE 125V 10A 4 648GB-11D-515 F51S10RA1FGNB
61 616 121 3501 TERMINAL FUSE 4 648GB-11D-510 1CC4S30500020
62 616 900 0028 FUSE 125V 5A 4 648GB-11D-514 F51S5R0A1FGNB
63 616 121 3525 END PLATE 1 648GB-11D-512 1CC4J36400090
64 616 121 3600 TERMINAL HOLDER 2 648GB-11D-523 1CC4J36200010
65 616 123 8344 CONDENSER 4 1CC4C11000170
66 411 119 2104 WASHER V 4X9X0.8 8 FW4 F
67 411 008 1706 WASHER SPR 4 8 SW4 F
68 630 000 7619 BOLT,HEX-SCT 8 M4X8
69 616 121 5048 ELECTROMAGNETIC SWITCH 1 648GC-11D-507 1CC4S23000260
70 411 119 2104 WASHER V 4X9X0.8 4 FW4 F
71 411 008 1706 WASHER SPR 4 4 SW4 F
72 411 043 5004 SCR PAN 4X8 4 M4X8 PAN
76 411 141 4305 WASHER V 6X12.5X1.6 3 FW6
77 411 141 3001 WASHER SPR 6 3 SW6
78 630 000 7886 BOLT,HEX-SCT 3 M6X16
NOTE
11-8
9703-001
MODEL TIM-1000L
