Key No. PART No. PART NAME Q'ty REMARKS REGISTERED No. 1 616 125 8656 BASE 1 648CB-11B-039 1CC2FA1001853 2 616 125 8694 HOLDER 2 648CB-11B-065 1CC2FC0507601 3 616 122 1858 INSULATOR 2 648CB-11B-067 1CC2CH1000030 4 6…
Key No. PART No. PART NAME Q'ty REMARKS REGISTERED No.
1 616 125 8656 BASE 1 648CB-11B-039 1CC2FA1001853
2 616 125 8694 HOLDER 2 648CB-11B-065 1CC2FC0507601
3 616 122 1858 INSULATOR 2 648CB-11B-067 1CC2CH1000030
4 616 125 8687 BLOCK 2 648CB-11B-055 1CC2FB1003002
5 616 122 2060 BUSH 4 648CB-11H-526 1CC4S60500200
6 411 141 4008 WASHER V 4X9X0.8 4 FW4
7 411 141 2905 WASHER SPR 4 4 SW4
8 630 000 7671 BOLT,HEX-SCT 4 M4X25
9 630 059 1354 UNIT,CAMERA 1 648CD-11H-501
9 -1 630 059 1354 UNIT,CAMERA 1 648CB-11H-520
10 630 063 2774 SCOPE UNIT 1 648CD-11H-503
11 630 064 0014 SCOPE UNIT 1 648CB-11H-522
12 411 141 6903 WASHER V 2X5X0.3 4 FW2
13 411 141 2608 WASHER SPR 2 4 SW2
14 630 000 7466 BOLT,HEX-SCT 4 M2X6
15 411 141 3902 WASHER V 3X7X0.5 4 FW3
16 411 141 2806 WASHER SPR 3 4 SW3
17 630 000 7510 BOLT,HEX-SCT 4 M3X8
18 616 125 8717 HOLDER 2 648CB-11B-071 1CC2FC0508760
19 630 000 7619 BOLT,HEX-SCT 4 M4X8
20 411 141 3902 WASHER V 3X7X0.5 4 FW3
21 411 141 2806 WASHER SPR 3 4 SW3
22 630 000 7572 BOLT,HEX-SCT 4 M3X25
23 616 125 8700 SPACER 2 648CB-11B-069 1CC2FF0502372
24 630 000 7527 BOLT,HEX-SCT 4 M3X10
25 411 141 4008 WASHER V 4X9X0.8 4 FW4
26 411 141 2905 WASHER SPR 4 4 SW4
27 630 000 7626 BOLT,HEX-SCT 4 M4X10
28 616 902 1771 HOLDER 1 648CE-11B-008 1CC2FC0507381
29 630 000 7657 BOLT,HEX-SCT 2 M4X16
30 616 125 6669 HOLDER 1 648CE-11B-020 1CC2FC0507390
31 616 122 2909 MIRROR 1 648CE-11H-501 1CC2FK3000080
32 616 122 2916 PRINTED BOARD 1 648CE-11H-502 1CC4B17000013
33 411 119 1909 WASHER V 3X7X0.5 2 FW3 F
34 411 119 1909 WASHER V 3X7X0.5 2 FW3 F
35 411 041 8908 SCR PAN 3X6 2 M3X6 PAN
36 411 141 3902 WASHER V 3X7X0.5 4 FW3
37 411 141 2806 WASHER SPR 3 4 SW3
38 630 000 7527 BOLT,HEX-SCT 4 M3X10
39 616 125 6676 COVER 1 648CE-11B-024 1CC2CA0504970
40 411 050 5004 SCR TRS 3X6 2 M3X6 TRS
41 630 000 7619 BOLT,HEX-SCT 4 M4X8
NOTE
6-4
9703-001
MODEL TIM-1000L
