6 Single Functions SIPLACE 80S/F/G User’s Manual
6.3 Star Head Functions 80S Edition 07/97 from Software Version SR.010.xx
6 - 20
6.3.1.7 Star Step
This function is used for cycling the star on by one position. To implement this function proceed as follows:
●
In the menu "Head functions" with the aid of the
cursor keys
position the cursor bar over the menu item
"Star step".
●
Press the
Return key
. The star will be moved onwards one segment. Each time the
Return key
is pressed
the star will be moved on one segment. The current star position is displayed.
6.3.1.8 Head Reference Run
Upon activation of this function the head axes perform a reference run. Here the gantry axes x and y are
moved to a position over the reject box in order to drop components.
To launch the function "Head reference run" proceed as follows:
●
In the menu "Head functions" with the aid of the
cursor keys
position the cursor bar over the menu item
"Head reference run".
●
Press the
Return key
. The head axes will perform a reference run.
6.3.1.9 Actuate DP1 Axis
Upon activation of this function the nozzle at the DP1 axis is rotated by 90°.
To launch the function "Actuate DP1 axis" proceed as follows:
●
In the menu "Head functions" with the aid of the
cursor keys
position the cursor bar over the menu item
"Actuate DP1 axis".
●
Press the
Return key
. The nozzle at DP1 will be rotated once by 90°.
6.3.1.10 Actuate DP2 Axis
Upon activation of this function the nozzle at the DP2 axis is rotated by 90°.
To launch the function "Actuate DP2 axis" proceed as follows:
●
In the menu "Head functions" with the aid of the
cursor keys
position the cursor bar over the menu item
"Actuate DP2 axis".
●
Press the
Return key
. The nozzle at DP2 will be rotated once by 90°.
SIPLACE 80S/F/G User’s Manual 6 Single Functions
Edition 07/97 from Software Version SR.010.xx 6.3 Star Head Functions 80S
6 - 21
6.3.1.11 Actuate Centering Jaws
The menu "Actuate centering jaws" can only be accessed when the function "Mechanical component center-
ing" has been configured on the line computer. Upon activation of this function the centering jaws are actuated
once.
To launch the function "Actuate centering jaws" proceed as follows:
●
In the menu "Head functions" with the aid of the
cursor keys
position the cursor bar over the menu item
"Actuate centering jaws".
Press the
Return key
. The centering jaws will be actuated once.
6.3.2 CRDL
The menu "CRDL" can only be accessed and executed when this function is configured on the line computer.
The menu item "CRDL" is required for compensation of the CRDL tester and also for checking the accuracy of
the tester.
To call the menu item "CRDL" proceed as follows:
●
In the menu "Star head" with the aid of the
cursor keys
position the cursor bar over the menu item "CRDL".
●
Press the
Return key
. The menu "CRDL" will be displayed on the screen.
Fig. 6.3.5
SI 80 V 10.x
Rüstung :
BE - Zuführung Display errors
Confirm errors
Machine options
Software options Vision system
Error
State
Action
Single functions
Transportfkt.
Breitenverstell.
Portal 1
Transportfkt.
Breitenverstell.
Star head
:
:
:
Nullimpuls anfahren
Portal - Referenzlauf
Kopf
Prüfgerät
Pipettenkonf.
CRDL
Test R
Test L
Test D
Test Z
Compensate C
Compensate R
Compensate L
Test T
Pickup calibr. plate
Pickup component
:
:
:
Test C
Single functions
Version: X.X
C compensation value
R compensation value
L compensation value
6 Single Functions SIPLACE 80S/F/G User’s Manual
6.3 Star Head Functions 80S Edition 07/97 from Software Version SR.010.xx
6 - 22
●
To execute the individual functions position the cursor bar with the aid of the
cursor keys
over the corre-
sponding menu item, and then press the
Return key
. The tester will perform the function which has been
selected. In the righthand part of the menu "CRDL" the results of testing or compensation are displayed as
a value and the version of the CRDL software will be displayed.
NOTE
The default compensation values will be the values last saved.
●
As regards testing the "T" tantalum capacitors see Section 6.3.2.1.
6.3.2.1 Test Tantalum Capacitors
If, as described in Section 6.3.2, you want to test a tantalum capacitor, the following screen is displayed.
Fig. 6.3.6
●
To perform the test, position the cursor bar over the applicable nominal voltage of the tantalum capacitor.
Press the
Return key
. The tantalum capacitor will be tested.
●
To quit the menu "CRDL" press the
Esc key
.
SI 80 V 10.x
Rüstung :
BE - Zuführung Display errors
Confirm errors
Machine options
Software options Vision system
Error
State
Action
Single functions
Portal 1
Portal 2
Transportfkt.
Breitenverstell.
Portal 1
Portal 1
Portal 2
Transportfkt.
Breitenverstell.
Star head
Nutzen:
:
:
:
Warteposition anfah.
Nullimpuls anfahren
Portal - Referenzlauf
Kopf
Prüfgerät
Pipettenkonf.
CRDL
C prüfen
L prüfen
D prüfen
Z prüfen
C kompensieren
Compensate R
Compensate L
T prüfen
Test T
Nominal voltage: 4V
Nominal voltage: >10V
Nominal voltage: 6V
Nominal voltage: 8V
Single functions
