SIPLACE 80S/F/G User’s Manual 6 Single Functions
Edition 07/97 from Software Version SR.010.xx 6.3 Star Head Functions 80S
6 - 23
6.3.2.2 Pick Up Calibration Piece
NOTE
The function "Pick up calibration piece" is at the present time not yet available.
If you want to carry out R or L compensation you will first need to select the function "Pick up calibration
piece". When compensation is completed the calibration piece will be returned automatically.
To quit the menu "CRDL" press the
Esc key
.
NOTE
The procedure for compensation and testing is described in more detail in Section 9 of this introduction,
"Maintenance".
6.3.2.3 Pick up component
NOTE
The function "Pick up component" is at the present time not yet available.
In the menu "Pick up component" you can pick up a component from a track which you have selected and
have it tested. At the end of the test the component is discarded to the reject box.
6.3.3 Star Nozzle Configuration
The menu item "Star nozzle config." is used for displaying and testing the nozzle sizes of the nozzles located
on the placement head.
NOTE
Processing and confirmation is only possible when cluster and set-up have been specified. If a nozzle-
changer has been configured, it will no longer be possible to confirm manually.
To call the menu item "Star nozzle config." proceed as follows:
●
In the menu "Star head", with the aid of the
cursor keys
position the cursor bar over the menu item
"Star nozzle config.".
●
Press the
Return key
. The menu "Star nozzle config." will be displayed on the screen.
6 Single Functions SIPLACE 80S/F/G User’s Manual
6.3 Star Head Functions 80S Edition 07/97 from Software Version SR.010.xx
6 - 24
Fig. 6.3.7
●
To cycle the star on press the
space bar
.
●
To quit the menu "Display nozzle config." press the
Esc key
. On the screen the menu "Gantry 1" reappears.
To process or confirm the menu item "Star nozzle config." proceed as follows:
●
In the menu "Nozzle change 1 and 2" position the cursor bar with the aid of the
cursor keys
over the menu
item "Star nozzle config." and then press the
Return key
.
●
The menu "Star nozzle config." appears.
●
To cycle the star on, press the
space bar
.
●
To confirm a change in the nozzle allocation of the head press the
Return key
. Nozzles which need to be
changed are emphasized by means of an arrow below the column "Change nozzle" in the menu window.
●
This confirmation is necessary, when there are different nozzle configurations (programmed and actual),
for the status of the column "Programmed" to be transferred into the column "Actual". This new nozzle con-
figuration is saved to the machine data file "aktuell.ma". It is always the star position displayed in "Star
position top" which is processed. Before confirmation the nozzle at the segment will have to be changed
correspondingly.
When this processing work is finished the two columns ("Actual", "Programmed") must be identical.
●
To quit the menu "Display nozzle config." press the
Esc key
.
NOTE
If a nozzle-changer has been configured, it will no longer be possible to confirm manually.
Esc: abort
Star nozzle config.
Function
State
Action
:
:
:
Pos.
No.
1
2
3
4
5
6
7
8
9
10
11
Actual
312
312
312
312
312
312
312
312
312
312
312
Programmed
312
312
312
312
312
312
312
312
312
312
312
Nozzle configuration
Star position top: 4
Star position bottom: 2
Blank: Star step Ret: accept
to change
<=
12 312 312
<=
SIPLACE 80S/F/G User’s Manual 6 Single Functions
Edition 07/97 from Software Version SR.010.xx 6.3 Star Head Functions 80S
6 - 25
6.3.4 Nozzle Changer SP
NOTE
The "Nozzle changer SP" menu can only be executed when a nozzle-changer has been configured (specified
by the line computer).
With the nozzle-changer at the rotating head it is possible to pick up and return nozzles automatically.
Proceed as follows to call the menu item "Nozzle changer SP":
●
In the menu "Star head" use the cursor keys to move the cursor bar over the menu item "Nozzle changer
SP".
●
Press the
Return key
. The screen then displays the menu "Nozzle changer SP".
Fig. 6.3.8
SI 80 V 10.x
Rüstung :
BE - Zuführung Display errors
Confirm errors
Machine options
Software options
Vision system
Error
State
Action
Transportfkt.
Breitenverstell.
Transportfkt.
Breitenverstell.
:
:
:
Nullimpuls anfahren
Portal - Referenzlauf
Kopf
Prüfgerät
Pipettenkonf.
Magazine configuration
Magazine filling level
Replace one nozzle
Return all nozzles
Pickup all nozzles
Remove all nozzles
:
:
:
Single functions
Single functions
Gantry 1
Star head
Nozzle changer SP
Lock open
Lock closed
