6 Single Functions SIPLACE 80S/F/G User’s Manual
6.8 Functions: Wafflepack Changer Edition 07/97 from Software Version SR.010.xx
6 - 52
6.8.1.3 Fill Magazine Carrier
With the function "Fill magazine carrier" the current set-up of the wafflepack changer can be displayed.
To call this function proceed as follows:
●
In the menu "WPC functions" position the cursor bar with the aid of the
cursor keys
over the menu item "Fill
magazine carrier".
●
Press the
Return key
. The screen then displays the menu "Fill magazine carrier".
Fig. 6.8.4
The menu displays how many components are present on which levels.
A new filling level can be input for each level individually.
●
With the cursor bar select the level which you want to fill.
●
Confirm your selection with the
return key
. The input window "New fill. level" appears in the menu window.
This input window already shows the maximum filling level for the level selected.
●
You can input the filling level yourself for the level selected or you can accept the specified maximum filling
level. Confirm your selection with the
return key
.
Press the
Esc key
if you want to quit the menu "Fill magazine carrier" without making an entry or selecting a
function.
NOTE
You cannot type in more than the specified maximum fill level.
Inputting a new fill level will set an empty track back to "full".
If 0 is typed in as fill level no components will be picked up any longer from this magazine carrier.
Error
State
Action
Fill magazine carrier
Location
Esc: abort Ret.: new fill. level:
New fill. level
Filling level: 55
Ret. Esc.
Level Divis. Comp. name Number
1 1 1 PLCC 44 3
1 4 1 PLCC 84 18
1 18 1 PLCC 44 29
:
:
:
1 12 1 QFP 44 1
SIPLACE 80S/F/G User’s Manual 6 Single Functions
Edition 07/97 from Software Version SR.010.xx 6.8 Functions: Wafflepack Changer
6 - 53
6.8.1.4 Set Wafflepack Changer Full
With the function "Set WPC full" all wafflepack magazines of the wafflepack changer which are defined in the
set-up can be set to "full".
To call this function proceed as follows:
●
In the menu "WPC functions" position the cursor bar over the menu item "Set WPC full" with the aid of the
cursor keys
.
●
Press the
Return key
. All defined wafflepack magazines which are recognized as being "empty" are set to
"full".
●
Press the
start key
. Placement is continued using these filled magazine trays.
In this connection see also Section 5.4 "Component Handling".
6.8.1.5 Furnish level
With the function "Furnish level" wafflepack magazines from different levels can be made available.
To call this function proceed as follows:
●
In the menu "WPC functions" position the cursor bar over the menu item "Furnish level" with the aid of the
cursor keys
.
●
Press the
Return key
. The "Furnish level" menu is displayed on the screen.
Fig. 6.8.5
●
Type the number of the level which you wish to make available into the input window "Level".
●
Press the
Return key
. The wafflepack changer moves this level's wafflepack tray to the pick-up position.
SI80F V 10.x
Nutzen:
Rüstung :
Display errors Machine options
Error
State
Action
:
:
:
Einzelfunktionen
Transportfkt.
Breitenverstell.
WPC functions
WPC reference run
Nachfüllpos. anfahren
WPW vollsetzen
Ebene bereitstellen
Füllstand anzeigen
Transportstellung
Single functions
Furnish level
Level:
ESC: abort Ret: input
Single functions
Single function
6 Single Functions SIPLACE 80S/F/G User’s Manual
6.8 Functions: Wafflepack Changer Edition 07/97 from Software Version SR.010.xx
6 - 54
NOTE
If there is a wafflepack tray in the pick-up position, it will first be returned to its defined level.
Press the
Esc key
if you want to quit the menu "Furnish level" without making an entry or selecting a function.
6.8.1.6 Transport position
With the function "Transport position" the lift is moved to a safety position so that the wafflepack changer can
be transported without risk.
To call this function proceed as follows:
●
In the menu "WPC functions" position the cursor bar over the menu item "WPC reference run" with the aid
of the
cursor keys
.
●
Press the
Return key
. A wafflepack which is in active use will be returned to its defined level and the lift of
the wafflepack changer moves to its bottom position.
6.8.1.7 WPC Reference Run
The function "WPC reference run" is used to reference the wafflepack changer.
To call this function proceed as follows:
●
In the menu "WPC functions" position the cursor bar over the menu item "WPC reference run" with the aid
of the
cursor keys
.
●
Press the
Return key
. A wafflepack which is in active use will be returned to its defined level. The lift of the
wafflepack changer carries out a reference run.
With the
Esc key
you can return to the menu "Single functions".
NOTE
The WPC version will also be indicated.
To call this function proceed as follows:
●
In the menu "WPC functions" with the aid of the
cursor keys
position the cursor bar over the menu item
"Transport position".
●
Press the
Return key
. A wafflepack in active use will be returned to its defined level and the lift positioned in
the lowest position.
6.8.2 Select Wafflepack Changer
If multiple wafflepack changers are being used with a SIPLACE 80 F a specific wafflepack changer can be
selected with the function "Select WPC".
At present operation with multiple wafflepack changers is not yet available.
6.8.3 Table functions
The functions of this menu item are described in more detail in Section 6.9 "Table functions".
