0 Introduction SIPLACE 80S/F/G User’s Manual
0.2 Technical Data Edition 07/97 from Software Version SR.010.xx
0 - 14
0.2.2.3 IC Head
0.2.2.4 CRDL Tester 80F
See Section 0.2.1.3 CRDL Tester 80S
0.2.2.5 Boards, Components, Tapes (80F)
IC head
Number 1
Components to be assembled
Max. height:
PCB
thickness
+ PCB
warpage
+ Comp.
height
≤
13.5 mm
Min. height: 0.3 mm
Min. pitch: 0.4 mm
Dimensions: up to 55 mm x 55 mm (larger on request)
Weight up to 25 grams
Resolution of the d axis
0.005
o
Z axis stroke 50 mm
Programmable placement force (z axis) 1.0 to 10.0 N
Nozzle types 4
Component centering Fine pitch vision module
Boards, components, tapes (80F)
Boards (PCB) transport system In-line transport with width adjustment
PCB format
50 mm x 50 mm to 460 mm x 460 mm with PCB buffer
50 mm x 50 mm to 508 mm x 460 mm
without PCB buffer (upon request)
Component-free guide edge of the board 3 mm
Min. PCB thickness 0.5 mm
Max. PCB thickness 4.5 mm
Max. PCB warpage
Upwards : 4.5 mm less PCB thickness
Downwards: 0.5 mm plus PCB thickness
PCB change time 2.5 sec.
Max. number of 8 mm tapes 80
Tape reel diameter Max. 15" in the reel container
Component range 0402 to 55 mm x 55 mm (larger on request)
SIPLACE 80S/F/G User’s Manual 0 Introduction
Edition 07/97 from Software Version SR.010.xx 0.2 Technical Data
0 - 15
0.2.2.6 Interfaces 80F
See Section 0.2.1.5 Interfaces 80S
0.2.2.7 Connection and Installation Data 80F
Connection and Installation requirements Machine dimensions
System voltage 230/400V ± 10 % (50/60 Hz) Weight base module 1500 kg
System voltage
opt. e.g. for USA
110/208 V ± 10 % (50/60 Hz) Weight fully-equipped 2000 kg
Total connected load 5 kVA Length 1587 mm
Total output 5 kW Width 2425 mm
Fuse protection 3 x 16 A Height with warning light 1836 mm
Compressed air supply At least 6 bar 400 NL/min.
Machine footprint
Permissible surface load
> 1 t/m²
Permissible environmental influences Machine control
Room temperature Between 15°C and 35°C Control computer
PC 386,
RMOS operating system
Air humidity
30 to 75 % (on average not higher
than 45 %, so that under no cir-
cumstances will there be conden-
sation in or on the machine
Machine control
SIMICRO
Input / output control
Axis controller
Siemens axis controller
boards (digital)
Compressed air specification
Max. particle size by density, based on ISO/DIS 8573-1
(Class 1)
Maximum oil content
Class 1
Particle size 0.1 µm Particle density 0.01 mg/m³
Particle density 0.1 mg/m³ Pressure dewpoint Class 4
Dewpoint + 3°C
Noise emission values specified in accordance with DIN 45 649-1
Emission value at a workstation (L
pAc
) 70 dB (A)
DIN EN ISO 11204 (i)
Sound power level (L
WAc
) 84 dB (A)
E-DIN EN ISO 3744 (i)
353-9217
0 Introduction SIPLACE 80S/F/G User’s Manual
0.2 Technical Data Edition 07/97 from Software Version SR.010.xx
0 - 16
0.2.2.8 Wafflepack Changer
Wafflepack changer
Magazine size Max. 238 mm x 338 mm
Magazine height incl. component 15 mm (taller magazines will reduce the number of the trays
Holding capacity 28 trays for holding flatpack magazines
Number of component types Max. 200 for entire WPC
Change time (magazine / magazine)
≤
3 sec.
