SIPLACE 80S/F/G User’s Manual 7 Vision Systems
Edition 07/97 from Software Version SR.010.xx 7.6 Test Component
Line engineer 7 - 83
7.6.3.6 Menu “Edit GF data”
NOTE
The menu “Edit GF data” is only activated if you have already entered a GF number and a model exists for the
GF number selected.
Fig. 7.6.13
A description of the menu and its options will be found in Section 7.6.4.
Error
State
Action
Edit GF data
Maschinenoptionen Single functions
Softwareoptionen
:
:
:
BE - Zuführung
Cluster: NU3456789012345678NU
SI80 V 10.x
Vision system
Vision system
Vision system
Setup:
Version: 2133
Test component
Enter GF number
Pickup component
Display component
Measure component
Test component
Edit GF data
Change measure mode
Refill
Display errors
Test output
7 Vision Systems SIPLACE 80S/F/G User’s Manual
7.6 Test Component Edition 07/97 from Software Version SR.010.xx
7 - 84 Line engineer
7.6.3.7 Menu “Change measure mode”
After this menu item has been selected the menu “Change measure mode” together with its options for selec-
tion of the measurement modes “Size”, “Row”, “Corner”, “Lead”, “Grid” and “Ball” will be displayed.
Fig. 7.6.14
A description of the menu and its options will be found in Section 7.6.5.
Error
State
Action
Change measure mode
Maschinenoptionen Single functions
Softwareoptionen
:
:
:
BE - Zuführung
Cluster:
SI80 V 10.x
Vision system
Vision system
Vision system
Setup:
Version: 2133
Test component
Enter GF number
Pickup component
Display component
Measure component
Test component
Edit GF data
Change measure mode
Refill
Display errors
Test output
SIPLACE 80S/F/G User’s Manual 7 Vision Systems
Edition 07/97 from Software Version SR.010.xx 7.6 Test Component
Line engineer 7 - 85
7.6.3.8 Option “Refill”
If the track is emptied due to pick-up error then with this option you can refill the track. When you select it a
dialog window pops up.
Fig. 7.6.15
Error
State
Action
Refill components and set feeders full
Single functions
:
:
:
Cluster:
SI80 V 10.x
Vision system
Vision system
Vision system
Version: 2133
Setup:
Test component
Enter GF number
Pickup component
Display component
Measure component
Test component
Edit GF data
Change measure mode
Refill
Display errors
Test output
