- Key to Fig. 8.6.5
➀
With socket wrench UP/DOWN
➁
Clamping screw
➂
Stroke
➃
Docking pin
➄
Upper edge of the magnetic bar of the component table
➅
Lower edge of tray
➆
Nominal stroke (459 mm)
➇
Refill position (470 mm)
●
Undo the clamping screws at the feet (see Fig. 8.6.5) and using a 10 mm ball socket wrench rotate the
wafflepack changer downwards until the docking pin engages. The wafflepack changer must at this point
be aligned using the machine spirit level fitted to the wafflepack changer.
●
Tighten up the clamping screws and check the machine spirit level again.
●
Plug the lighting back into the components vision module.
8.6.10 Technical Data
Wafflepack-Changer
Length ca. 1475 mm
Width ca. 620 mm
Height ca. 1355 mm
Weight ca. 240 kg
Magazine size 238 mm x 338 mm
Vertical stroke 470 mm
Horizontal stroke 730 mm
Pitch 17 mm
Storage unit capacity 28 trays for holding flatpack magazines
Magazine carrier 260 mm x 360 mm
Max. weight of storage unit 50 kg
Floor load
< 25 N/cm
2
Changeover time (magazine/magazine)
≤
3 sec.
Tab. 8.6.1
8 Component Supply SIPLACE 80S/F/G User’s Manual
8.6 Wafflepack Changer Edition 07/97 from Software Version SR.010.xx
8 - 28
SIPLACE 80S/F/G User’s Manual 8 Component Supply
Edition 07/97 from Software Version SR.010.xx 8.7 Support for Flatpack Magazine (Manual Tray Support)
8 - 29
8.7 Support for Flatpack Magazine
(Manual Tray Support)
PLEASE NOTE
The manual tray holder must only be placed on the right side of the SIPLACE 80F. The tray holder can only be
positioned so that the right edge covers no more than track 73.
8.7.1 General
With the support for flatpack magazines components can be picked up from individual flatpack magazines.
The flatpack magazines are changed by hand.
The support for flatpack magazines is positioned on the component table like a conveyor.
There are two different versions of the support which differ in their width.
Support for large flatpack magazine (260 mm) Item No. 00116430-01
Support for small flatpack magazine (136 mm) Item No. 00116432-01
8.7.2 Installation
●
Insert the front side of the manual tray rest into the associated centering pin (B in Fig. 8.7.1).
●
Position the rear of the manual tray rest into the spherical cap on the component table (A in Fig. 8.7.1).
●
Make sure the manual tray rest is resting securely on the components table.
●
Position one side of the flatpack magazine carrier in the mounting (C in Fig. 8.7.1) and press the other side
into the mounting (D in Fig. 8.7.1).
●
Slide the flatpack magazine up against the stop (E in Fig. 8.7.1).
●
Secure the flatpack magazine carrier by pressing the clamp downwards (F in Fig. 8.7.1).
●
To remove the flatpack magazine carrier press the clamp once more.
NOTE
With the "mounting for small flatpack magazine" (136 mm) a flatpack magazine (JEDEC or CENELEC flatpack
magazines) can be fitted directly to the mounting, in other words, without a flatpack magazine carrier being
used. The clamp will however need changing.
8.7.2.1 Changing the Clamp
●
Hold the retainer firmly (G in Fig. 8.7.1). Press the clamp (F in Fig. 8.7.1) downwards and remove the
retainer by pressing it out sideways.
