9 Maintenance SIPLACE 80S/F/G User’s Manual
9.1 Overview Edition 07/97 from Software Version SR.010.xx
9 - 8
9.1.5 Tools and Consumables Required for Maintaining the
SIPLACE 80S, 80F and G Placement Machines
The lists of materials stated below indicate all of the tools, equipment and consumables required for maintain-
ing the SIPLACE 80S/F/G machines.
NOTE
•
Always use soft, clean and lint-free cloths for cleaning work.
•
Do not use any solvents, use ethyl alcohol only!
•
Apply all lubricants and all oil only sparingly and only where required.
9.1.5.1 List of Materials Required for Maintenance of the SIPLACE 80S Placement
Machines
For maintenance you will require the tools and equipment listed below:
Tools, Equipment Item number
Brush
Brush with short bristles
Calibrating unit RLCD 00306034-01
Collecting pan
Grease gun 02101695-01
Hexagon socket screw key, set of
Laboratory gloves, white
Marker pen, permanent
Oilstone
Segment removal tool for V1 segments 02101789-01
Segment removal tool for V2 segments 00305897-02
Segment storage case 00302217-01
Standard screwdrivers, set of
Tweezers
Vacuum cleaner
Work gloves, strong
HS/SP/WPC/ SIPLACE 80 component table platform truck 00123141-01
Tab. 9.1.1 Tools and equipment required for maintenance of the SIPLACE 80S placement machine
SIPLACE 80S/F/G User’s Manual 9 Maintenance
Edition 07/97 from Software Version SR.010.xx 9.1 Overview
9 - 9
9.1.5.2 List of Materials Required for Maintenance of the SIPLACE 80F Machine
The lists of materials required for maintenance of the SIPLACE 80S placement machine also apply to the
SIPLACE 80F. In addition you will need:
9.1.5.3 List of Materials Required for Maintenance of the SIPLACE G Adh. Appl.
Machines
For maintenance of the SIPLACE G adhesive application machine you will additionally require the tools and
equipment listed below:
Consumables Item number
Cloth, lint-free
Ethyl alcohol
Filter mat 230 x 360 00315209-01
Segment maintenance cloth 00315253-01
Soapy water
Staburags N12 lubrication grease 02100611-01
Tissue
Unimoly GL 82 00310282-01
Unisilkon L250L 00310259-01
Urethyn E/M2, grease cartridge 02101696-01
Watchmaker’s oil, 5 ml 02100393-01
WD 40 anti-corrosive agent 00325833-01
Tab. 9.1.2 Consumables required for maintenance of the SIPLACE 80S placement machine
Tools and equipment Item number
Change-over table lifting cart HS/SP/WPW/SIPLACE 80 00123141-01
Nozzle removal tool 00311448-01
Tab. 9.1.3 Additional tools and equipment required for maintenance of the SIPLACE 80F placement machine
Consumables
Lens cleaning cloth, moisture-sealed pack
Lens cleaning tissue (from Kodak, for example)
Talcum
Tab. 9.1.4 Additional consumables required for maintenance of the SIPLACE 80F placement machine
Tools, Equipment Item number
Cleaning bolt 00308575-06
Universal ultra-sonic cleaning bath 02102349-01
Tab. 9.1.5 Tools and equipment required for maintenance of the SIPLACE G adhesive application machine
