9 Maintenance SIPLACE 80S /F/G User’s Manual 9.9 Adhesive Application Heads 1, 2 and 3 Edition 07/97 f rom Software Version SR.010.xx 9 - 104 9.9.3 Removing the Glue Cartridges and Cleaning the Glue Nozzles 9.9.3.1 Remov…

SIPLACE 80S/F/G User’s Manual 9 Maintenance

Edition 07/97 from Software Version SR.010.xx 9.9 Adhesive Application Heads 1, 2 and 3

9 - 103

Fig. 9.9.3 Maintenance work on adhesive application head 1

9 Maintenance SIPLACE 80S/F/G User’s Manual

9.9 Adhesive Application Heads 1, 2 and 3 Edition 07/97 from Software Version SR.010.xx

9 - 104

9.9.3 Removing the Glue Cartridges and Cleaning the Glue Nozzles

9.9.3.1 Removing the Glue Cartridges and Detaching the Glue Nozzle

Fig. 9.9.4 Removing the glue cartridge and detaching the glue nozzle

Key to Fig.9.9.4 Sequence in Fig. 9.9.4

NOTE

The spacers of adhesive heads 1 and 2 are identical.

1 Conical glue nozzle

2Spacer

3 Split washer

4 Cylindrical glue nozzle

5Spacer

6 Glue nozzle with spacer

A Loosen the knurled screw

B Hold against the cartridge

C Hold the dispenser unit and pull up

D Swivel the cartridge out a little and lift up to remove

E Turn the spacer and pull down to remove

F Unscrew the glue nozzle

SIPLACE 80S/F/G User’s Manual 9 Maintenance

Edition 07/97 from Software Version SR.010.xx 9.9 Adhesive Application Heads 1, 2 and 3

9 - 105

NOTE:

When refitted, the allocation and position of the spacers with respect to the adhesive application heads must

be the same as before, i.e. the spacer of adhesive application head 3 must be refitted to head 3 and the posi-

tion of the spacer must be correct. The spacers of adhesive heads 1 and 2 are identical.

NOTE

When installing ensure that, after fixing the new glue cartridge, the dispenser unit is guided downwards and is

not moved down too quickly by the force of the spring.

9.9.3.2 Cleaning the Adhesive Nozzles

NOTE

Carry out cleaning of the adhesive nozzles before the other maintenance work on the adhesive application

heads so that the adhesive does not dry out in the nozzles.

CAUTION

∆

For the following work you will require a solvent or synthetic-resin solvent. This presents a fire hazard!

There will therefore be an increased risk of accident! Do not perform the following work under any circum-

stances in the vicinity of fire. Close off the working area around the ultrasonic bath correspondingly, and also

while the nozzles are drying.

Work only if there is adequate air extraction!

Maintenance frequencies:

Aluminum - nozzles After 1 week's operation or 24 hours out of service

Aluminum PTFE- nozzles After 2 weeks' operation or 48 hours out of service

Conical aluminum/PTFE nozzles After 2 weeks' operation or 48 hours out of service

Spare parts:

Aluminum nozzles: Will be replaced by aluminum PTFE nozzles

Aluminum PTFE- nozzles

Size 0.30 mm Item No. 00317870-01

Size 0.44 mm Item No. 00317871-01

Size 0.60 mm Item No. 00317872-01

Conical aluminum/PTFE nozzles

Size 0.10 mm Item No. 00305554-06

Size 0.15 mm Item No. 00305555-06

Size 0.2 mm Item No. 00305556-06

Size 0.25 mm Item No. 00305557-06

Size 0.3 mm Item No. 00305558-06
