10.6 Display Functions
10.6.1 Display Errors
In the menu "Display errors" various classes of errors can be called up and displayed. The menu "Machine
errors" can be accessed under the "Display errors" menu as well as under various error menus.
In the main menu use the cursor keys to select the menu item "Display errors". Then press the
Return key
. On
the screen the menu "Display errors" is displayed.
Fig. 10.6.1
10.6.1.1 Machine errors display
Under the menu "Display errors" use the cursor keys to select the menu item "Machine errors" or under the
active error menu the menu item "machine errors". Then press the
Return key
. On the screen the menu
"Machine errors " will be displayed.
SI 80G V 10.x
Cluster:
Display errors
Confirm errors
Machine options
Error
State
Action
:
:
:
Rüstung :
Machine errors
Display errors
Transport errors
General errors
10 SIPLACE G SIPLACE 80S/F/G User’s Manual
10.6 Display Functions Edition 07/97 from Software Version SR.010.xx
10 - 36
Fig. 10.6.2
Key functions
-
With the
cursor keys
↑
and
↓
you can scroll through the display line by line.
-
With the keys
Bild auf
↑
[PgUp] and
Bild ab
↓
[PgDn] you can scroll through the display page by page.
-
With the key
Pos1
you can jump to the start of the display and with the key
Ende
to the last position of the
display.
-
With the key
Esc
you can quit the menu. On the screen the menu is displayed under which the menu
"machine errors" had been called.
-
With the key
Entf
you can delete all machine errors which have occurred and which are shown in this
menu.
The column "ENo" indicates the error number.
The column"ER" indicates how often the error has already occurred.
The column "GU" indicates the glueing unit.
The column "DEV" indicates the originator.
Error
State
Action
Machine errors
ENo TEXT
GU DEV ER
: up
: dn
Bild auf [Page up]
Bild ab [Page dn]
Pos1: begin
Ende: end
Esc: abort
Entf: delete
:
:
:
Error treatment - machine error
Last error displayed on top
