SIPLACE 80S/F/G User’s Manual 19 Error Messages
Edition 12/96 from Software Version SR.009.xx 19.1 Error Messages
19 - 13
138 Insuff. number of nozzles in changer magazine SP to pick up
CAUSE
●
Nozzles are to be picked up
⇒
With optical garage check: All garages have been checked with the board camera and are empty
Without optical garage check: One or more garages of the required nozzle type is empty.
REMEDY
●
The corresponding magazines must be set full via the menu.
139 No cluster available for nozzle pick-up SP
CAUSE
●
No cluster has been specified as specified selection.
REMEDY
●
Specifiy placement program in the line computer.
140 Nozzle-changer SP head cannot be unlocked
CAUSE
●
Key plate for locking the nozzle-changer magazine cannot be unlocked.
The plate is jamming mechanically, due to components etc.
Incorrect compressed air setting for the actuating cylinder; lacking air pressure;
the cylinder or valve is defective.
REMEDY
●
Correction of the above causes
141 Nozzle-changer SP head cannot be locked
CAUSE
●
Key plate for locking the nozzle-changer magazine cannot be unlocked.
The plate is jamming mechanically, due to components etc.
Incorrect compressed air setting for the actuating cylinder; lacking air pressure;
the cylinder or valve is defective.
REMEDY
●
Correction of the above causes
142 Communication with vision system during nozzle check faulty
CAUSE
●
Communication with the vision system is faulty.
REMEDY
●
Switch the system on and off (reset); notify SMD Service Department.
143 Desired Z-axis position exceeded during nozzle SP pick-up
CAUSE
●
The position of the x and y axes in the machine data is not correct;
the desired position of the z axis is not correct; there is no nozzle in the garage.
REMEDY
●
Correction of the above causes
19 Error Messages SIPLACE 80S/F/G User’s Manual
19.1 Error Messages Edition 12/96 from Software Version SR.009.xx
19 - 14
144 Desired z axis position not reached during nozzle SP pick-up
CAUSE
●
The position of the x and y axes in the machine data is not correct (sleeve is not positioned over the
garage);
desired position of the z axis is not correct; there is already a nozzle at the sleeve.
REMEDY
●
Correction of the above causes
145 Desired z axis position exceeded during nozzle SP return
CAUSE
●
The position of the x and y axes in the machine data is not correct;
desired position of the z axis is not correct; there is no nozzle at the sleeve.
REMEDY
●
Correction of the above causes
146 Desired Z-axis position not reached during nozzle SP return
CAUSE
●
The position of the x and y axes in the machine data is not correct (sleeve is not positioned over the
garage);
desired position of the z axis is not correct; there is already a nozzle in the garage.
REMEDY
●
Correction of the above cause
147 Desired Z-axis position exceeded during nozzle SP rejection
CAUSE
●
The position of the x and y axes in the machine data is not correct ;
desired position of the z axis is not correct; there is no nozzle at the sleeve.
REMEDY
●
Correction of the above causes
148 Desired Z-axis position not reached during nozzle SP rejection
CAUSE
●
The position of the x and y axes in the machine data is not correct (sleeve not above garage);
desired position of the z axis is not correct; there is already a nozzle in the garage.
REMEDY
●
Correction of the above causes
SIPLACE 80S/F/G User’s Manual 19 Error Messages
Edition 12/96 from Software Version SR.009.xx 19.1 Error Messages
19 - 15
149 Nozzle SP change not completed
CAUSE
●
This error message is issued when after an automatic change the actual state of the nozzle configu-
ration does not yet correspond with the desired state.
REMEDY
●
In the menu "Display errors" list the error and case by case:
set the magazine(s) full;
set up nozzle-changer;
select the menu "Pick up all nozzles";
NOTE
While this is running when there is a fault the magazine and garage numbers will be displayed in the "Gen-
eral errors" menu.
The following will apply: Info1 = Magazine number
Info2 = Garage number
150 Nozzle SP pick-up not completed
CAUSE
●
During automatic change or when the "Pick up all nozzles" menu was called it was not possible to
pick up all nozzles because:
there are too few nozzles in the corresponding magazine;.
the magazine is empty or was not installed.
REMEDY
●
In the menu "Display error" list the error and case by case:
set the magazine(s) full;
set up nozzle-changer;
select the menu "Pick up all nozzles";
NOTE
While this is running when there is a fault the magazine and garage numbers will be displayed in the "Gen-
eral errors" menu.
The following will apply: Info1 = Magazine number
Info2 = Garage number
151 Nozzle return/discard SP not completed
CAUSE
●
During automatic change or when the "Return all nozzles" menu was called it was not possible to
return all nozzles because:
there are no enough empty garages in the corresponding magazine.
although the magazine is full, setting full was not confirmed.
REMEDY
●
Nozzles which could not be returned will be ejected into the rejects tray.
