SIPLACE 80S/F/G User’s Manual 19 Error Messages
Edition 12/96 from Software Version SR.009.xx 19.1 Error Messages
19 - 15
149 Nozzle SP change not completed
CAUSE
●
This error message is issued when after an automatic change the actual state of the nozzle configu-
ration does not yet correspond with the desired state.
REMEDY
●
In the menu "Display errors" list the error and case by case:
set the magazine(s) full;
set up nozzle-changer;
select the menu "Pick up all nozzles";
NOTE
While this is running when there is a fault the magazine and garage numbers will be displayed in the "Gen-
eral errors" menu.
The following will apply: Info1 = Magazine number
Info2 = Garage number
150 Nozzle SP pick-up not completed
CAUSE
●
During automatic change or when the "Pick up all nozzles" menu was called it was not possible to
pick up all nozzles because:
there are too few nozzles in the corresponding magazine;.
the magazine is empty or was not installed.
REMEDY
●
In the menu "Display error" list the error and case by case:
set the magazine(s) full;
set up nozzle-changer;
select the menu "Pick up all nozzles";
NOTE
While this is running when there is a fault the magazine and garage numbers will be displayed in the "Gen-
eral errors" menu.
The following will apply: Info1 = Magazine number
Info2 = Garage number
151 Nozzle return/discard SP not completed
CAUSE
●
During automatic change or when the "Return all nozzles" menu was called it was not possible to
return all nozzles because:
there are no enough empty garages in the corresponding magazine.
although the magazine is full, setting full was not confirmed.
REMEDY
●
Nozzles which could not be returned will be ejected into the rejects tray.
19 Error Messages SIPLACE 80S/F/G User’s Manual
19.1 Error Messages Edition 12/96 from Software Version SR.009.xx
19 - 16
NOTE
While this is running when there is a fault the magazine and garage numbers will be displayed in the "Gen-
eral errors" menu.
The following will apply: Info1 = Magazine number
Info2 = Garage number
153 Ceramic substrate centering: x clamp cannot be opened
CAUSE
●
Air pressure is absent; valve incorrectly set; bero defective; mechanical problems
REMEDY
●
Check air pressure; adjust valve; check bero; check mechanism
154 Ceramic substrate centering: x clamp cannot be locked
CAUSE
●
Valve set incorrectly; bero defective; mechanical problems
REMEDY
●
Adjust valve; check bero; check mechanism
155 Conveyor belt target width outside travel range
CAUSE
●
Conveyor belt target width specified by the line computer for the automatic width adjustment is
> 460 mm or < 50 mm
REMEDY
●
Input the target width of the board (which will lie within the minimum and maximum target widths)
into the line computer
156 Conveyor belt target width cannot be set (timeout)
CAUSE
●
Emergency stop during automatic width adjustment; bero on the moveable side of the conveyor is
defective or not set correctly; width adjustment motor is defective
REMEDY
●
Check bero or motor
157 Both limit switches of width adjustment actuated
CAUSE
●
Limit switch of the conveyor belt width adjustment is defective
REMEDY
●
Check the limit switches
SIPLACE 80S/F/G User’s Manual 19 Error Messages
Edition 12/96 from Software Version SR.009.xx 19.1 Error Messages
19 - 17
158 Limit switch of width adjustment for minimum width actuated
CAUSE
●
Conveyor belt width has been set too small
REMEDY
●
Increase conveyor belt width
159 Limit switch of width adjustment for maximum width actuated
CAUSE
●
Conveyor belt width has been set too large
REMEDY
●
Reduce conveyor belt width
160 Bero not found during conveyor belt width check
CAUSE
●
Conveyor belt bero is defective or set incorrectly
REMEDY
●
Check bero
161 Bero covered before conveyor belt width check
CAUSE
●
Conveyor belt bero responds before the actual position (gantry) is reached
REMEDY
●
Adjust bero
162 WPC must be moved from refill position
CAUSE
●
WPC is in the refill position
REMEDY
●
The operator should quit the refill position in the "Refill" "Location1" menu.
163 Conveyor belt width out of travel range
CAUSE
●
The conveyor width detected lies outside of the possible range of values.
The sensing distance of the bero has been set too high.
The bero is defective.
REMEDY
●
Use the SITEST program to re-register the 100mm board and run width measurement again.
The sensing distance of the bero has been set too high.
Replace bero.
