19 Error Messages SIPLACE 80S/F/G User’s Manual
19.1 Error Messages Edition 12/96 from Software Version SR.009.xx
19 - 106
911 OPT: Spacer in contact with glueing point
CAUSE
●
Glueing points are too close together or their position relative to the spacer is not good.
REMEDY
●
Reposition the spacer and reoptimize the cluster.
NOTE
The spacer angle must be input in the "Modify system data" menu.
912 DP: axis type incorrect in small gantry mapping data
CAUSE
●
Incorrect axis type in the RASTER.K1 file (mapping data for glueing station for small gantries)
REMEDY
●
Make the necessary correction in the machine file RASTER.K1 (axis type).
913 DP: errors in gantry ident. in small gantry map. data
CAUSE
●
Incorrect gantry identification in RASTER.K1 file (mapping data for glueing station for small gantries)
REMEDY
●
Make the necessary correction in the machine file RASTER.K1 (axis type).
1001 Undefined error message
CAUSE
●
Error does not occur
REMEDY
●
1002 Undefined error message
CAUSE
●
Error does not occur
REMEDY
●
1003 Undefined error message
CAUSE
●
Error does not occur
REMEDY
●
SIPLACE 80S/F/G User’s Manual 19 Error Messages
Edition 12/96 from Software Version SR.009.xx 19.1 Error Messages
19 - 107
1004 Undefined error message
CAUSE
●
Error does not occur
REMEDY
●
1005 z axis; GU1: Bero at top does not react
CAUSE
●
z1 axis is not positioned high enough; Bero defective; z1 axis is jamming
motor, controller, servo-amplifier defective.
REMEDY
●
Check the components just mentioned.
1006 Glue: z axis; GU2: Bero at top does not react
CAUSE
●
z2 axis is not positioned high enough; Bero defective; z2 axis is jamming
motor, controller, servo-amplifier defective.
REMEDY
●
Check the components just mentioned.
1007 Glue: z axis; GU3: Bero at top does not react
CAUSE
●
z3 axis is not positioned high enough; Bero defective; z3 axis is jamming
motor, controller, servo-amplifier defective.
REMEDY
●
Check the components just mentioned.
1008 Undefined error message
CAUSE
●
Error does not occur
REMEDY
●
1009 Undefined error message
CAUSE
●
Error does not occur
REMEDY
●
19 Error Messages SIPLACE 80S/F/G User’s Manual
19.1 Error Messages Edition 12/96 from Software Version SR.009.xx
19 - 108
1010 Glue: z axis; GU1: cannot be moved any further upwards
CAUSE
●
When the start button is pressed the z12 axis is below the minimum position
REMEDY
●
The servo-amplifier should be checked; slide the z1 axis upwards by hand
1011 Glue: z axis; GU2: cannot be moved any further upwards
CAUSE
●
When the start button is pressed the z2 axis is below the minimum position
REMEDY
●
The servo-amplifier should be checked; slide the z2 axis upwards by hand
1012 Glue: z axis; GU3: cannot be moved any further upwards
CAUSE
●
When the start button is pressed the z3 axis is below the minimum position
REMEDY
●
The servo-amplifier should be checked; slide the z3 axis upwards by hand
1013 xk axis: Position outside of travel range
CAUSE
●
Not used
REMEDY
●
1014 yk axis: Position outside of travel range
CAUSE
●
Not used
REMEDY
●
1015 z axis; GU1: Position outside of travel range
CAUSE
●
Not used
REMEDY
●
1016 z axis; GU2: Position outside of travel range
CAUSE
●
Not used
REMEDY
●
