第 1 部基本篇第 1 章设备概要 ··············· 1-1 第 2 章生产 ················· 2-1 第 3 章维护 ················· 3-1 第 4 章制作生产程序 ············· 4-1 第 5 章数据库 ················ 5-1

8-4-2-2 自动控制传送 ··············································································· 8-19

8-4-2-3 自动调整基板宽度控制 ··································································· 8-20

8-4-3 其它······································································································ 8-21

8-4-3-1 信号灯控制 ·················································································· 8-21

8-4-3-2 其它传感器 ·················································································· 8-22

8-4-3-3 驱动状况 ····················································································· 8-23

第 9 章设备运行信息

9-1 概要 ················································································································ 9-1

9-2 机器运行信息 ···································································································· 9-1

9-3 试胶单元运行信息 ······························································································ 9-4

9-3-1 试胶单元运行信息 ······················································································ 9-4

9-3-2 次数设置 ·································································································· 9-5

9-3-3 警告级别设置 ···························································································· 9-7

9-3-4 错误级别设置 ···························································································· 9-7

9-4 各点胶头的运行信息 ··························································································· 9-8

9-4-1 各点胶头的运行信息 ··················································································· 9-8

9-4-2 次数设置 ·································································································· 9-9

9-4-3 警告级别设置 ·························································································· 9-11

9-4-4 错误级别设置 ·························································································· 9-11

9-5 其它运行信息 ·································································································· 9-12

9-5-1 信号灯运行信息 ······················································································· 9-12

9-5-2 OCC 运行信息 ························································································ 9-13

9-5-3 轴运行信息 ····························································································· 9-14

9-5-4 传送运行信息 ·························································································· 9-15

9-5-5 异步运行信息 ·························································································· 9-16

9-5-6 坏

板标记传感器运行信息（选项） ······························································· 9-17

9-5-7 应用程序运行信息 ···················································································· 9-18

9-6 运行信息数据的重设处理 ··················································································· 9-19

9-6-1 通过对话框方式重新设置全部运行信息 ························································· 9-19

9-6-2 在重新设置选项选择画面上重新设置运行信息 ················································ 9-20

9-6-3 设备运行数据全部初始化 ··········································································· 9-22

第 10 章选项元件的使用

10-1 坏板标记传感器 ······························································································ 10-1

10-2 外部抽气单元 ································································································· 10-3

第 11 章程序补充

11-1 控制数据管理 ································································································· 11-1

11-2 各用户级别可使用的功能 ················································································· 11-10

11-3 生产程序的文件格式 ······················································································· 11-11

11-4 作为用户指定模板的可登录模式 ········································································ 11-13

11-5 开始生产时的检查 ·························································································· 11-14

11-6 维护日志 ······································································································ 11-17

11-7 记录工具（Log Tool） ···················································································· 11-18

11-8 自动取得记录功能 ·························································································· 11-19

第12章附录

12-1 点胶数据一览表 ························································································· 12-1

第 1 部基本篇

第 1 章设备概要 ··············· 1-1

第 2 章生产 ················· 2-1

第 3 章维护 ················· 3-1

第 4 章制作生产程序 ············· 4-1

第 5 章数据库 ················ 5-1

第 1 部基本篇第 1 章设备概要

第 1 章设备概要

1-1 本设备的概要

1-1-1 前言

本装置是是用于点胶表面实装元件所使用的胶粘剂的装置，其外观和基本构成均以

KE-2070/2080 为基础，可以通过以太网（Ethernet）进行 Network（注 1．可选项）

控制。

对于其 OS（基本软件），由以往机种（KD-775）对应的 DOS，改良为 WindowsXP，大

幅提高了操作性。

通过组合的提高车间生产性支援系统，对 JUKI 贴片机及点胶机上与生产相关的各种

业务和信息，以车间（＝制造现场）为单位进行涵盖管理、优化，实现整体车间的生产

性、制造品质的提高，提高效率、降低成本。

● 基板规格和构成

KD-2077

对应语言日语、英语、中文

基

板

规

格

基板尺寸

最小尺寸（L×W）：50×30mm 注 1.

最大尺寸（L×W）：410×360mm

基板厚度 0.4～4.0mm

传送方向向右传送、向左传送

传送基准前基准、后面基准

传送高度 900mm±20mm、950mm±20mm（可选项）

构

成

点胶头构成

1 头

注射器根数 3 根（30cc 注射器）

注 1：附带基板宽度自动调整功能时为 50×50mm
