RL131
ERROR CODE LIST
2.3 Error Code Table
DA8EEC-91-030-A0
2.3-5
Error code Message
2696
No PCB on XY table
2707
H axis origin off
2708
Feeder float detection error
2710
Safety relay reset condition
2712
An error occurred during origin returning for any of C, X, Y, θH, θA or P. Origin return of all axes
canceled.
2713
The θH axis is not at its origin. Origin return of all axes canceled.
2714
The θU axis is not at the waiting position. Origin return of all axes canceled.
2715
An error occurred during origin returning for the θU axis. Origin return of all axes canceled.
2731
PCB carry in restart cancel
2732
PCB carry out restart cancel
2733
PCB sweep out restart cancel
2734
PCB carry start conditional not satisfies
2735
Rail down condition not satisfies
2736
Arm carry condition not satisfies
2737
Arm slowdown condition not satisfies
2738
Rail up condition not satisfies
2739
Arm return condition not satisfies
2748
Emergency stop switch ON safety stop
2756
Axis related error
2757
PCB recognition error (23)
2758
PCB recognition error (16)
2759
PCB recognition error (17)
2760
PCB recognition error (19)
2761
PCB recognition error (45)
2762
PCB recognition error (47)
2763
PCB recognition error (48)
2764
PCB recognition error
2765
PCB recognition error
2766
PCB recognition error
2767
PCB recognition error
2768
Part processing stage cover safety detection
2769
Pulley part cover safety detection
2770
No Pallet part
2771
Pallet part catch error
2772
V cut tape remainder error
2773
V cut return error
2774
Supply unit move error
2777
Feeder move error (Return)
2778
Stockout detect error
4066
This is write protected disk. Please release write protect. Refer to Help for detail.
4067
There is no signature on boot sector. Refer to Help for detail.
9293
Driver soft interlock
9294
Soft task comm. Error
9295
Soft calculation error
9304
Motion incomplete
9305
Soft parameter error
9308
Soft overrun limit
9369
Exclusion process error
9372
Position interrupt error
RL131
ERROR CODE LIST
2.3 Error Code Table
DA8EEC-91-030-A0
2.3-6
Error code Message
9373
Complete interrupt error
9400
Axis error
9801
Auto width power on error
9802
Auto width origin return incomplete
9803
Auto width positioning incomplete
9804
Auto width emergency stop input
9805
Auto width command error
9806
Auto width parameter error
9807
Auto width communication error
9809
Auto width origin abnormal
9812
Auto width + overrun error
9813
Auto width - over run error
RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-1
2.4. Errors
DA8EEC-91-210-A0
7
Emergency switch ON
DESCRIPTION
Emergency switch was detected.
CAUSE
An emergency stop switch was pressed.
SOLUTION
Release the emergency stop switch. (There are five switches. Front; 2 Rear; 3) If the same message appears after
releasing the switch, the switch may be broken. Confirm emergency SW signal in the [Input check] of [Machine
adjustment].
NOTE
8
Servo switch OFF
DESCRIPTION
Servo switch off
CAUSE
A servo switch is pressed.
SOLUTION
Release the servo switch (1 in front and 1 in back). (KEYLOCK LED of operation panel turns OFF.)
If the same message appears after releasing the switch, the switch may be broken.
NOTE
9
Air pressure drop
DESCRIPTION
Air pressure drop
CAUSE
Air pressure has dropped.
SOLUTION
When supplied air pressure has dropped, supply air at 0.49MPa - 0.78MPa.
Excessively high setting of the air pressure detector causes an error. Set to 0.4MPa.
Confirm Air pressure (5800H:bit2) in the [input check menu] of [machine adjustment]. ON: OK, OFF: Drop
NOTE
12
Cover open stop
DESCRIPTION
Door or cover is open
CAUSE
Safety cover is left open.
SOLUTION
Close the door or cover, then push [return].
Confirm Cover switch (5800H:bit3, 4, 5) in the [input check menu] of [machine adjustment]. ON: Close, OFF: Open
NOTE
17
PCB transport error
DESCRIPTION
PCB remains at the transferring part, or PCB is broken.
CAUSE
PCB cannot be transferred properly.
SOLUTION
Check the PCB transfer unit for proper operation.
NOTE
