RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-2
34
Counter error
DESCRIPTION
Counter error of axis controller
CAUSE
Trouble of axis controller board in CPU box
SOLUTION
Necessary to exchange axis controller board.
Please inform us the axis name and the situation.
NOTE
35
Returning to origin error
DESCRIPTION
Incomplete returning to origin
CAUSE
Axis can't move smoothly.
Motor driver trouble
Trouble of axis controller board in CPU box
Getting loose of motor coupling
Disconnection of motor wiring
Trouble of axis I/O sensor
SOLUTION
Inspection of axis. (Dust etc.)
Exchange motor driver.
Exchange axis controller board.
Confirm I/O sensor status in the [Input check menu] of [Machine adjustment]. Check 1260H, 1261H, 1262H, 1263H,
9806H, 9816H, 9826H, A006H, A016H, A026H, A806H, A816H, A826H, A836H, B006H, B016H, B026H, B036H.
Please inform us the axis name and the situation.
NOTE
37
Data error (Soft limit)
DESCRIPTION
Move data beyond limit is sent to axis controller.
CAUSE
Move data beyond limit exists in pickup position data and mount data.
SOLUTION
Check pickup position data and mount data.
Please inform us the axis name and the situation.
NOTE
38
(+) Overrun
DESCRIPTION
Axis (+) overrun sensor is ON.
CAUSE
Trouble of sensor
SOLUTION
Execute return to origin in the [Ret orig] of [Machine adjustment].
[Confirm I/O sensor status in the [Input check menu] of [Machine adjustment].
Confirm setting of CPU box board (MCMJEX) and connection of connector.
Please inform us the axis name and the situation.
NOTE
RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-3
39
(-) Overrun
DESCRIPTION
Axis (-) overrun sensor is ON.
CAUSE
Trouble of sensor
SOLUTION
Execute return to origin in the [Ret orig] of [Machine adjustment].
Confirm I/O sensor status in the [Input check menu] of [Machine adjustment].
Confirm setting of CPU box board (MCMJEX) and connection of connector.
Please inform us the axis name and the situation.
NOTE
40
Driver error
DESCRIPTION
A motor driver error was detected
CAUSE
The motor drive detected an error.
SOLUTION
Confirm error code of 7 segment LED of error occurred axis driver.
Power OFF and ON, leave 5 minutes in main menu then restart.
Please inform us the axis name^ error code of 7 segment LED and the situation.
NOTE
47
Interlock error
DESCRIPTION
Unregistered interlock error occurred.
CAUSE
NC board detected an error of an unregistered axis number.
SOLUTION
Please inform us the axis name and the situation.
If restart is impossible, once power OFF/ON.
NOTE
49
Axis controller communication error
DESCRIPTION
No response from axis controller.
CAUSE
No response against command to axis controller.
SOLUTION
Please inform us the axis name and the situation.
NOTE
51
Conveyor width adjust error
DESCRIPTION
Unable to width adjust because PCB exist on the conveyor.
CAUSE
Width cannot be adjusted when there is a PCB on the conveyor because it may drop or get caught.
SOLUTION
Remove PCB.
NOTE
53
Power box over heat
DESCRIPTION
Temperature in power box is high.
CAUSE
Temperature in power box is over the reference value.
SOLUTION
Check fan moving.
NOTE
RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-4
54
CPU box over heat
DESCRIPTION
Temperature in CPU box is high.
CAUSE
Temperature in CPU box is over the reference value.
SOLUTION
Check fan moving.
NOTE
61
Safety relay error
DESCRIPTION
Problem occurs in safety relay.
CAUSE
Safety relay may be faulty.
SOLUTION
Power OFF and ON. Please inform us situation.
NOTE
112
Illegal product data
DESCRIPTION
Production data check detects an error in self diagnosis.
CAUSE
Production data has an error.
SOLUTION
Check the error item at [Data check] in [Data modification] and correct data.
NOTE
1203
PCB Recognition Error
DESCRIPTION
A PCB recognition error was detected.
CAUSE
Insertion position may be incorrect.
Part may already have been inserted.
Lighting for recognition may not be lit.
SOLUTION
Modify the insertion position to the correct coordinates.
Check the condition of the insertion position.
Check the condition of the lighting.
NOTE
1236
Momentary power failure error
DESCRIPTION
Low voltage, power failure, Momentary power failure was detected.
CAUSE
The voltage of the R-S phase or the S-T phase is lack of phase more than 24ms.
SOLUTION
Please turn off the main switch and turn on the main switch again. Please confirm the voltage of power supply when
the error occurs repeatedly.
NOTE
