RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-4
54
CPU box over heat
DESCRIPTION
Temperature in CPU box is high.
CAUSE
Temperature in CPU box is over the reference value.
SOLUTION
Check fan moving.
NOTE
61
Safety relay error
DESCRIPTION
Problem occurs in safety relay.
CAUSE
Safety relay may be faulty.
SOLUTION
Power OFF and ON. Please inform us situation.
NOTE
112
Illegal product data
DESCRIPTION
Production data check detects an error in self diagnosis.
CAUSE
Production data has an error.
SOLUTION
Check the error item at [Data check] in [Data modification] and correct data.
NOTE
1203
PCB Recognition Error
DESCRIPTION
A PCB recognition error was detected.
CAUSE
Insertion position may be incorrect.
Part may already have been inserted.
Lighting for recognition may not be lit.
SOLUTION
Modify the insertion position to the correct coordinates.
Check the condition of the insertion position.
Check the condition of the lighting.
NOTE
1236
Momentary power failure error
DESCRIPTION
Low voltage, power failure, Momentary power failure was detected.
CAUSE
The voltage of the R-S phase or the S-T phase is lack of phase more than 24ms.
SOLUTION
Please turn off the main switch and turn on the main switch again. Please confirm the voltage of power supply when
the error occurs repeatedly.
NOTE
RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-5
1239
Code Error
DESCRIPTION
Software error was occurred.
CAUSE
Software codes may be abnormal.
SOLUTION
Call the Servicing Department of our company.
NOTE
1250
DriverReadyTimeOut
DESCRIPTION
The axis driver condition does not become Ready.
CAUSE
The axis controller or servo driver may have failed.
SOLUTION
Call the Servicing Department of our company.
NOTE
1300
Emergency stop switch
DESCRIPTION
Emergency stop switch is kept pressed.
CAUSE
Emergency stop signal was detected.
SOLUTION
Please pull and release the emergency stop switch.
NOTE
1301
Servo switch
DESCRIPTION
Servo switch is OFF.
CAUSE
Servo switch OFF signal was detected.
SOLUTION
Turn ON the servo switch.
NOTE
1302
Cover open
DESCRIPTION
Cover is open.
CAUSE
Safety cover is left open.
SOLUTION
Close the cover.
NOTE
1303
Air pressure
DESCRIPTION
Air pressure is down.
CAUSE
Air pressure is lower than the standard value or the air is not supplied.
SOLUTION
Feed the air at the pressure between 0.49MPa - 0.78MPa.
NOTE
RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-6
1304
Pre Process Production End
DESCRIPTION
Ending signal from preceding process has been detected.
CAUSE
Preceding machine is sending the signal of ending the production.
SOLUTION
Turn OFF the Ending signal from preceding process.
NOTE
1306
Data check
DESCRIPTION
Data do not satisfy the production condition.
CAUSE
Data condition required for production is insufficient.
SOLUTION
Enter the Data modification mode and press the data check key to confirm NG data items. And then change data.
NOTE
1310
Driver condition
DESCRIPTION
Trouble is found in the servo driver.
CAUSE
Servo driver alarm signal was detected.
SOLUTION
Cancel the driver error.
NOTE
1314
Safety relay
DESCRIPTION
Safety relay has not been properly reset.
CAUSE
There are some troubles in the safety relay.
SOLUTION
Replace the safety relay.
NOTE
1316
Thermal trip (Pump)
DESCRIPTION
Thermal switch for the Pump has detected overcurrent.
CAUSE
Thermal switch for the Pump was activated due to overcurrent.
SOLUTION
Reset the thermal relay.
NOTE
1516
Driver communication error
DESCRIPTION
Communication with an axial driver went wrong.
CAUSE
Communication error between the NC board and driver was detected.
SOLUTION
Call the Servicing Department of our company.
NOTE
