RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-7
1700
XY interlock (Right rail)
DESCRIPTION
Interlock was detected between XY table and right rail.
CAUSE
While XY table is moving right rail traverse limit sensor (80000:bit0) was detected.
SOLUTION
Please confirm whether right rail is down position. Please confirm right rail traverse limit sensor.
NOTE
1701
XY interlock (Left rail)
DESCRIPTION
Interlock was detected between XY table and left rail.
CAUSE
While XY table is moving left rail traverse limit sensor (80040:bit4) was detected.
SOLUTION
Please confirm whether left rail is down position. Please confirm left rail traverse limit sensor.
NOTE
1702
Auto width interlock
DESCRIPTION
Auto width interlock was detected.
CAUSE
Interlock signal was input while auto width running.
It tried to operate auto width axis with the interlock signal input.
SOLUTION
Please confirm interlock signal. Interlock signal to which the auto width refers is as follows.
<Interlock signal> PCB detection 1 (80000:bit2) PCB detection 2 (80000:bit3) PCB detection 3 (80040:bit6) PCB
detection 4 (80040:bit7) XY table PCB detection (80003:bit0)
Right belt motor output (Positive rotation 80020:bit2) (Reverse rotation 80020:bit3)
Left belt motor output (Positive rotation 80060:bit2) (Reverse rotation 80060:bit3)
Safety cover (80581:bit0/bit1/bit2/bit3) Emergency input (80581:bit4/bit5/bit6/bit7)
XY axis origin (NC origin) H axis origin (M.ORG)
NOTE
1703
Air down interlock
DESCRIPTION
Air pressure was down.
CAUSE
Air down sensor (80002:bit5) was detected while machine was running.
SOLUTION
Please confirm whether the air pressure is correct.
NOTE
1705
Handle interlock
DESCRIPTION
Pushing H axis rotation wheel was detected.
CAUSE
H axis wheel detection (800C3:bit2) was detected while H axis was running.
SOLUTION
Please return H axis rotation wheel to original position.
NOTE
RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-8
1708
Power failure interlock
DESCRIPTION
The power failure was detected while the machine was running.
CAUSE
Power failure (80580:bit7) was detected while the machine was running.
SOLUTION
Please turn power failure reset signal (805A0:bit7) on and off by the [Output check] of [Machine adjustment] to reset
power failure.
NOTE
1710
θA axis plus overrun interlock
DESCRIPTION
The plus overrun interlock of the θA axis was detected.
CAUSE
θA plus overrun (80041:bit4) was detected while the θA axis was running. θA axis is located near mechanical
stopper.
SOLUTION
Please confirm θA plus overrun detection. Please confirm θA axis position.
NOTE
1711
θA axis minus overrun interlock
DESCRIPTION
The minus overrun interlock of the θA axis was detected.
CAUSE
θA minus overrun (80041:bit6) was detected while the θA axis was running. θA axis is located near mechanical
stopper.
SOLUTION
Please confirm θA minus overrun detection. Please confirm θA axis position.
NOTE
1714
X axis plus/minus overrun interlock
DESCRIPTION
The plus/minus overrun interlock of the X axis was detected.
CAUSE
X plus/minus overrun (80582:bit5) was detected while the X axis was running. X axis is located near mechanical
stopper.
SOLUTION
Please confirm X plus/minus overrun detection. Please confirm X axis position.
NOTE
1715
Y axis plus/minus overrun interlock
DESCRIPTION
The plus/minus overrun interlock of the Y axis was detected
CAUSE
Y plus/minus overrun (80582:bit4) was detected while the Y axis was running. Y axis is located near mechanical
stopper.
SOLUTION
Please confirm Y plus/minus overrun detection. Please confirm Y axis position.
NOTE
1718
Ring IO communication interlock
DESCRIPTION
RING IO communication interlock was detected.
CAUSE
There is a possibility of coming off and the disconnection of the RING communication optical cable.
SOLUTION
Please confirm the RING communication optical cable.
NOTE
RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-9
1720
Axis Moving interlock
DESCRIPTION
Direct start signal was off while axes was running.
CAUSE
Axis was not completed within its timing by the axis moving delay.
Direct start signal was off due to the power failure.
The direct start signal was off by the disconnection of cycle timer rotary encoder.
SOLUTION
Please confirm the axis where the error display. Please confirm axis movement is smooth, and confirm there is no
groan or Vibration.
Please release the power failure and restart operation.
Please confirm the state of the rotary encoder.
NOTE
1809
Servo ready off error
DESCRIPTION
The axis where the error occurred is not in NC ready status.
CAUSE
Ready input signal for the servo amplifier or NC board remains OFF.
SOLUTION
Check the condition of the servo amplifier, motor and NC/IO board.
NOTE
1811
(+) Overrun error
DESCRIPTION
Plus limit sensor for the axis where the error occurred was turned ON.
CAUSE
Plus limit sensor input was detected while the axis was moving (including starting to move) in the positive direction
for positioning or teaching.
SOLUTION
Close the error screen and move the axis in the negative direction. Or returning the axis to its origin also will do.
NOTE
1812
(-) Overrun error
DESCRIPTION
Minus limit sensor for the axis where the error occurred was turned ON.
CAUSE
Minus limit sensor input was detected while the axis was moving (including starting to move) in the negative direction
for positioning or teaching.
SOLUTION
Close the error screen and move the axis in the positive direction. Or returning the axis to its origin also will do.
NOTE
1815
Driver comm. Error
DESCRIPTION
Between motor and NC board^communication error occured.
CAUSE
NC board did not receive any network command in a few second.
SOLUTION
Please confirm the connection of cable between motor and NC board.
If there are many electric noises on that cable^please rewire that cable.
Please turn off the machine.|If you do not solve this error please change that cable.
Please inform us situation.
NOTE
