RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-23
1894
USB4 overcurrent alarm
DESCRIPTION
The USB4 overcurrent alarm of CPU board was detected.
CAUSE
There is a possibility that CPU board is out of order.
SOLUTION
Please contact our service section.
NOTE
1895
USB5 overcurrent alarm
DESCRIPTION
The USB5 overcurrent alarm of CPU board was detected.
CAUSE
There is a possibility that CPU board is out of order.
SOLUTION
Please contact our service section.
NOTE
1896
CF access impossible
DESCRIPTION
It was not able to access CF on CPU board.
CAUSE
There is a possibility that CPU board is out of order.
SOLUTION
Please contact our service section.
NOTE
1897
Power ON first Safety Stop
DESCRIPTION
Machine is under safety stop condition.
CAUSE
Whenever machine was turned on, it becomes safety stop condition.
SOLUTION
Please continue the operation after press return button to close error screen.
NOTE
1900
Maintenance mode switching error
DESCRIPTION
Production menu was selected during maintenance.
CAUSE
Production menu is restricted during maintenance.
SOLUTION
Release the maintenance mode.
NOTE
1901
Maintenance switch abnormal
DESCRIPTION
Maintenance switch was detected abnormally.
CAUSE
Maintenance switch was detected with the cover closed.
(1) Cover switch has been sort-circuited intentionally.
(2) Faulty maintenance switch
SOLUTION
Do not short-circuit the cover switch intentionally.
Check the detected state of the maintenance switch.
NOTE
RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-24
1920
Feeder install error
DESCRIPTION
The feeder installation is abnormal.
CAUSE
The feeders may not have been installed properly.
SOLUTION
Check the installation condition of the feeders.
NOTE
2003
PCB carry in restart cancel (right rail belt)
DESCRIPTION
The restart of the PCB carrying in was canceled.
CAUSE
When the carrying in operation was restarted by the safety stop release, PCB was detected at the right rail exit.
SOLUTION
Please restart the operation after confirming PCB on a right rail.
NOTE
2011
PCB carry in restart cancel (right rail exit)
DESCRIPTION
The restart of the PCB carrying in was canceled.
CAUSE
When the carrying in operation was restarted by the safety stop release, PCB was detected at the right rail exit.
SOLUTION
Please restart the operation after confirming PCB on a right rail.
NOTE
2012
PCB carry in restart cancel (right rail exit)
DESCRIPTION
The restart of the PCB carrying in was canceled.
CAUSE
When the carrying in operation was restarted by the safety stop release, PCB was detected at the right rail exit.
SOLUTION
Please restart the operation after confirming PCB on a right rail.
NOTE
2052
PCB carry out restart cancel (left rail belt)
DESCRIPTION
The restart of the PCB carrying out was canceled.
CAUSE
When the carrying out operation was restarted by the safety stop release, PCB was detected at the left rail exit.
SOLUTION
Please restart the operation after confirming PCB on a left rail.
NOTE
2079
PCB carry out restart cancel (left rail exit)
DESCRIPTION
The restart of the PCB carrying out was canceled.
CAUSE
When the carrying out operation was restarted by the safety stop release, PCB was detected at the left rail exit.
SOLUTION
Please restart the operation after confirming PCB on a left rail.
NOTE
RL131
ERROR CODE LIST
2.4 Errors
DA8EEC-91-210-A0
2.4-25
2209
Rail down condition not satisfies (left rail return limit)
DESCRIPTION
Rail down action was not done, because of the lack of the rail down condition.
CAUSE
Left rail return limit has been turned off.
SOLUTION
It is necessary to have turned on the left rail return limit to down rail.
NOTE
2216
Rail down condition not satisfies (positioner lever return limit)
DESCRIPTION
Rail down action was not done, because of the lack of the rail down condition.
CAUSE
Positioner lever return limit has been turned off.
SOLUTION
It is necessary to have turned on the positioner lever return limit to down rail.
NOTE
2221
Rail down condition not satisfies (right rail return limit)
DESCRIPTION
Rail down action was not done, because of the lack of the rail down condition.
CAUSE
Right rail return limit has been turned off.
SOLUTION
It is necessary to have turned on the right rail return limit to down rail.
NOTE
2223
Rail down condition not satisfies (servo switch)
DESCRIPTION
Rail down action was not done, because of the lack of the rail down condition.
CAUSE
Servo switch has been turned off.
SOLUTION
It is necessary to have turned on the servo switch to down rail.
NOTE
2225
Rail down condition not satisfies (transfer arm return limit)
DESCRIPTION
Rail down action was not done, because of the lack of the rail down condition.
CAUSE
Transfer arm return limit has been turned off.
SOLUTION
It is necessary to have turned on the transfer arm return limit to down rail.
NOTE
2231
Rail down condition not satisfies (XY origin)
DESCRIPTION
Rail down action was not done, because of the lack of the rail down condition.
CAUSE
X or Y axis origin sensor has been turned off.
SOLUTION
It is necessary to have turned on the X and Y axis origin sensor to down rail.
NOTE
