Component Handling
X Feeder Error Messages on X Feeder
369 Student Guide SIPLACE X-Serie and X4I SW70x (AL2)
Error Messages on X Feeder
10.2.8 Error Messages on X Feeder
When the feeder is ready for operation, you will see a green LED. Warnings and error messages are
shown by orange or red LEDs and a text on the LCD display.
Warnings
View of feeder settings
If the feeder data transfer is disabled in SIPLACE Pro and
if the data from the programming system and the feeder
do not match, a warning will be issued or the fields will be
marked red (see adjacent diagram).
View of feeder settings
The data can now be manually changed using the
buttons in the relevant line.
Display LED
display
Meaning Troubleshooting
Remove Foil
(Folie
entfernen)
Orange Unable to perform the
function selected with the
cover foil stretched tight
(foil rocker is pushed
down).
If the required function is to be
performed, remove the foil from
the toothed wheels and cut it to
relax the foil rocket.
Component Handling
Error Messages on X Feeder X Feeder
Student Guide SIPLACE X-Serie and X4I SW70x (AL2) 370
Error messages
Display LED
display
Meaning Troubleshooting
None Red,
flashing
Application software not
present or faulty →
software remains in boot
loader.
Reload the application software.
Handle
(Griff)
Red The feeder module has
been logged in but the
removal handle has not yet
been engaged (pushed in).
Push in the handle until it
engages.
Low Voltage
(Unter-
spannung)
Orange 24V supply voltage has not
reached the switching-on
threshold after being
switched on.
Check the voltage supply.
Low Voltage
(Unter-
spannung)
Red 24V supply voltage has
exceeded the switching-on
threshold and has then
collapsed.
Check the voltage supply.
Feed Timeout
TransTimeout
(Zeitfehler beim
Gurttransport-
zyklus)
Red Tape transport cycle was
not completed correctly in
the set time (timeout for
function "Feed").
Is the tape reel trapped in the
container?
Is the component trapped in the
pickup area, between the tape
and the component window?
Once you have solved the
blockage, reinitiate the feed-in
with the arrow buttons. The
feeder module will finish the
faulty feed run and will return to
its correct position.
Foil Torn
(Folie gerissen)
Red Foil was not tensioned
within the prescribed time.
The foil has probably been torn.
Reinsert the foil and re-tension
it.
Foil PeelErr
(Fehler beim
Abziehen der
Folie)
Red Foil has not been correctly
stripped off, although the
tape is being fed in.
The cover foil has probably been
trapped under the pickup
window and therefore not
stripped off properly.
Foil Jam
(Folienstau)
Red Foil motor jammed Toothed wheels blocked by foil?
Component Handling
Pneumatic Tape Cutter Pneumatic Tape Cutter and Empty Tape Duct
371 Student Guide SIPLACE X-Serie and X4I SW70x (AL2)
Pneumatic Ta pe Cutter
10.3 Pneumatic Tape Cutter
Pneumatic Tape Cutter and Empty Tape Duct
10.3.1 Pneumatic Tape Cutter and Empty Tape Duct
The pneumatic tape cutter unit is fixed to the frame of the docking unit with 4 screws. It separates plastic,
aluminum and paper tapes up to a maximum pocket depth of 25 mm. The tape clippings fall down the
waste slide, into the waste tape bin of the component trolley.
The empty tape duct is constructed so that it covers the cutting edges of the tape cutter (for safety), so
that it controls movement of the empty component tapes to the cutter, so that the component reject bin
is integrated and so that it can receive the various nozzle changers for the C&P6/12/20 and TwinHead.
EEP-WriteErr
(Fehler bei der
Datensicherung
im EEPROM)
Red Data backup has not been
performed correctly in the
EEPROM.
Since the position of the drive is
stored in the EEPROM, a
reference run is necessary in
these cases. → Acknowledge
the error with the gray button.
Now confirm request to perform
reference run, with the yellow
button (see Reference Run for
details).
EEP-ReadErr
(Fehler beim
Auslesen des
EEPROMS)
Red Data from the EEPROM
have not been correctly
read.
EEP-DataErr
(Fehler beim
Sichern der
Daten im
EEPROM)
Red Data backup has not been
performed completely in
the EEPROM.
Reference
Referenz o
Red Tape drive position
information is not available.
Remove the tape. Then perform
a reference run by pressing the
yellow "Foil" button.
CAN BusError
(CAN-Bus-
Fehler)
Red CAN Bus Error If pressing reset does not solve
the problem, send the feeder in
for repairs.
ParNotSaved!
Red The parameters were not
saved.
The default parameters are
automatically loaded i.e. the last
operator settings are overwritten
→ you may need to change
settings (e.g. cycle). If this error
occurs frequently, replace the
control board.
ParWrongSave
Red Parameters were
incorrectly or incompletely
saved.
BootFlashErr
FlashDataErr
Red Unable to correctly write
data in boot or application
memory.
Replace feeder or control board.
Display LED
display
Meaning Troubleshooting
