SIPLACE X Series Siplace X Series Specifications (Excerpt)
49 Student Guide SIPLACE X-Serie and X4I SW70x (AL2)
Siplace X Series Specifications (Excerpt)
3.1.3 Siplace X Series Specifications (Excerpt)
Specification details Value
Placement performance with example of X4i with C&P20A
Benchmark 120.000 cph
Theoretical value 135.000 cph
IPC value 102.000 cph
C&P20A placement head
Component spectrum 01005 to 2220, Melf, SOT, SOD
Component dimensions (LxW) 6x6 mm
CO height 4.0 mm
CO weight 1 g
Placement accuracy X/Y accuracy:
± 41 μm (3 sigma); ± 55 μm (4 sigma)
Angle accuracy
± 0.5° / (3 sigma); ± 0.7° / (4 sigma)
Placement force 1.5 -4.5 N
Placement mode Collect and Place
Placement performance (benchmark) 30.000 cph
TwinHead placement head
Component spectrum 0201 to SO, PLCC, QFP, socket, connector, BGA, Bare
Die, Shield, FlipChip
Component dimensions (LxW)
in operation with one segment 85x85 mm (125x10 mm)
in operation with both segments 50x50 mm (69x10 mm)
CO height 25 mm
CO weight 30 g, max.100 g
Placement accuracy X/Y accuracy:
± 26 μm / 3σ, ± 35 μm / 4σ ± 22 μm / 3σ, ± 30 μm / 4σ
Angle accuracy
± 0.05° / 3σ, ± 0.07° / 4σ ± 0.05° / 3σ, ± 0.07° / 4σ
Placement force 1-15 N, max.30 N High Force TH
Placement mode Pick and Place
Placement performance (benchmark) 5.000 cph
CPP placement head
Component spectrum 0201 to SO, PLCC, QFP, socket, connector, BGA, Bare
Die, Shield, FlipChip
Component dimensions (LxW) 32x32 mm (C&P mode), 50x40 mm (P&P mode)
CO height CPP_L 6.0 mm, CPP_H 8.5-11.5 mm
CO weight 4 g in C&P mode, 8 g in P&P mode
Placement accuracy ± 55 µm / 4 sigma in C&P mode,
± 45 - ± 55 µm / 4 sigma depending on component camera
(mixed mode)
± 45 µm /4 sigma in P&P mode
Placement force 1-10 N
Placement mode Collect and Place, mixed mode, Pick and Place
Placement performance (benchmark) 23.500 cph in C&P mode, 15000 cph in P&P mode
Overview
Overview of Placement Head Component Heights SIPLACE X Series
Student Guide SIPLACE X-Serie and X4I SW70x (AL2) 50
Overview of P lacement Head Componen t Heights
3.1.4 Overview of Placement Head Component Heights
Locations
Number of changeover tables 4
Number of slots for 8 mm X feeder per
table
40
Number of slots for 8 mm X feeder per
table, location 2/4 for X4I
34
Feeder types X feeder 8-88 mm
LDU (Linear Dipping Unit)
Label presenter
Adapter X feeders
Reject module
MTC2 location 2/4
Conveyor systems Single conveyor
Dual conveyor
Quad lane conveyor
PCB changeover time <2.5s
PCB weight 3 kg
Minimum distance to PCB 3.0 mm
PCB thickness 0.3–4.5mm
Conveyor speed 50-450 mm/s
Fixed conveyor sides Right, left, outer
Conveyor widths
Single conveyor Standard 460 mm, max. 533 mm
Dual conveyor Standard 216 mm, max. 250 mm
Flexible dual conveyor as single conveyor Standard 380 mm, max. 450 mm
Quad lane conveyor 114 mm
PCB lengths Standard 450 mm (X4I max. 380 mm)
"Long Board" option max. 610 mm
Machine connection values
Electrical Connections 3 x 200 V~ ± 5 %; 50/60 Hz (Japan)
3 x 208 V~ ± 5 %; 50/60 Hz (U.S.A)
3 x 400 V~ ± 5 %; 50/60 Hz (Europe)
Pneumatic connection values min. 0.5 MPa = 5.0 bar
max.1.0 MPa = 10 bar
NOTICE
These values are only an excerpt from the specifications! The full specifications can be found
in the operating manual or in the specification documentation for the X series machines!
Specification details Value
Placement heads Maximum component height
CPP_L 8.5 mm (11.5 mm on request)
CPP_H 6.0 mm
C&P20A 4.0 mm
Twin Head 25.0 mm
Overview
Overview of Components Power supply
51 Student Guide SIPLACE X-Serie and X4I SW70x (AL2)
Overview of Com ponents
3.2 Overview of Components
SIPLACE X4I - top view
Legend
Power supply
3.2.1 Power supply
The main power supply unit is mounted on a compact rack unit and is located on the left in the middle
section of the machine. From outside, you can only see the red main switch.
A lockable door prevents access to the power supply.
1 Sector 1 7 Location for component table 40 tracks,
each with 8 mm X feeder
2 Sector 2 (main distributor) 8 Computer unit
3 Sector 3 9 Location for component table 34 tracks,
each with 8 mm X feeder
4 Sector 4 (subdistributor) 10 Axis unit placement area 1 (PA1)
5 Transport direction 11 Axis unit placement area 2 (PA2)
6 Pneumatic unit & conveyor control 12 Power supply unit
