Edition 1 .0 IPS Adjustment for V arious Head T ypes on the Module <H08MQ head > FK - 9F50 - 74 -0 E 6- 10 FUJI CORPORA TION 4. Adjust the pos ition o f the ca mera so th at t he jig s on the B and H hol ders match…
Edition 1.0
IPS Adjustment for Various Head Types on the Module
<H08MQ head>
FK-9F50-74-0E
6-9
FUJI CORPORATION
Adjusting t he c a mer a ins tallation posit ion
1. Press the low er but t on t o return to “ADJ MODE”.
2. Use Equipment Check to turn the following I/Os ON.
Y10C Lower Transport Height C ommand
Y10D Lower IPS Back Comm and
3. Press the low er but t on t o enter “ ADJ USTM E NT 1” mode.
CONFIDENTIAL
Edition 1.0
IPS Adjustment for Various Head Types on the Module
<H08MQ head>
FK-9F50-74-0E
6-10
FUJI CORPORATION
4. Adjust the position o f the camera so th at t he jig s on the B and H hol ders match up w ith
the green frames on t he screen.
5. Loosen the bolts on t he left and r i ght , and move t he camera b ack and forth to adjust
the pitch o f jig nozzles.
If the monit or i m age free zes during t he adjustme nt, it is necessary to return
to ADJUSTM ENT 1 and enter ADJUSTMENT 1 again.
6. Loosen the 3 bolts and move the camera in the XY direction so the nozzles
align with the green frames on the LCD monitor. Then check that the center
values, res ol ution and tilt are within tolerance.
Left a s vie wed f rom
front
Right as viewed
from front
CONFIDENTIAL
Edition 1.0
IPS Adjustment for Various Head Types on the Module
<H08MQ head>
FK-9F50-74-0E
6-11
FUJI CORPORATION
7. Press the low er but t on t o save t he s et t ings.
8. Remov e t he jigs
Inspection item
Tolerance
LED current adjustm ent
Adjust the current value s o that the GR and GL gray values
are within the range 95 to 250. The target value is 100 +/-
5. Current = 26 mA or below.
Camera resolution
check
L: X = 90 ~ 100
L: Z = 90 ~ 100
Center val ue
R: Xs = 390 ± 20
Zp = 320 ± 20
L: Xp = 90 ± 25
Zp = 320 ±10
Tilt
R: dX = 0~9 (Target: 0), dZ = 0~9 (Target: 0)
L: dX = 0~9 (Target: 0
）
, dZ = 0~9 (Target: 0)
Resolution values
Center val ues
Tilt v alues
