Edition
1.0 IPS Adjustment for Various Hea d Types on the Module
<H12L head>
FK-9F50-74-0E 8-3 FUJI CORPORATION
9 After starting communication, the current servo counter of each axis are
displayed. Recor d ser vo counters of Axis 3 (R-axis) and Axis 4 (Q-axis).
Original position of R-axis
0 to 60000 pulses
Original position of Q-axis
30000 ± 500 pulses
10 Press the PO WER but t on to enter s lee p mode and turn OFF the head power.
11 Attach the IPS monitor jig to the head. C onnect so that the blue side of the harness tip
faces outwar d (refer to the photo below).
12 Press the POWER button to wake.
13 Startup Equipm ent Ch eck and select M achine.
R-axis
Q-axis
CONFIDENTIAL
Edition
1.0 IPS Adjustment for Various Hea d Types on the Module
<H12L head>
FK-9F50-74-0E 8-4 FUJI CORPORATION
14 Select the mod ul e and select [ M odule] ⇒ [CPU].
15 Supply power t o t he head by t he follow in g pr ocedure .
● Put a check in [Output operation].
● Y003 SERVO CONTROL POWER HE AD POWER : ON
● Y002 MASTER ON : ON
● Y001 MACHINE READY OK : ON ⇒ OFF
● X000 SAFETY RELAY OK , X001 SAFETY OK (DEL AY) : ON
Confir m that t he I PS monitor jig scr een is displayed.
● Remove the chec k from [Output O per at ion].
16 Startup MotionAdjustmentTool. After starting communication, the current servo counter
of each axis are displayed. Move the R-axis (Axis 3) t o i ts original position (0 ~ 60000
pulses) and the Q-axis (Axis 4) to it s original position (30000 ± 500 pulses).
Be careful not to move from thi s position!
CONFIDENTIAL
Edition
1.0 IPS Adjustment for Various Hea d Types on the Module
<H12L head>
FK-9F50-74-0E 8-5 FUJI CORPORATION
Component nam e s and e x planation of the a djustment modes
Mode name: displays the curr ent ly s el ected adjustment mo de.
Back butt on: used t o switch t o a different mode from t he cur r ent ly selected mode.
Set button: us ed when saving or when selecting modes.
There are 6 different adjustme nt m odes.
Mode name
Contents
AUTO MODE
The initial screen displayed when the power is supplied to
the head.
ADJ MODE
This mode is used to acce ss t he 3 adjustme nt modes below.
ADJUSTMENT 1
Used for res ol ut ion and ti lt adjustment.
ADJUSTMENT 2
Used for gray scale and cu r r ent value adjustment.
ADJUSTMENT 3
Used to chec k the field of vision.
CONFIGURATION
Used to set t he function settings.
Mode name
Back butt on
Set button
