Edition
1.0 IPS Adjustment for Various Hea d Types on the Module
<H12L head>
FK-9F50-74-0E 8-6 FUJI CORPORATION
Configur a t ion setti ngs
1. Make sure that "IPS TYP E" is 2G and "HA RD TYPE" is 15.
2. If not, hold down the lower butt on and ent er "ADJ MO DE".
3. In the "ADJ MODE" screen, press the upper and lower buttons at the same time to
display the " CONFIG U RATION" screen.
4. Press the upper button to make "IPS TYPE" 2G and "HARD TYPE" 15, then press the
lower button t o save the s et ting.
5. Reboot the base if you change the s et t ings.
Select TYPE
Save
CONFIDENTIAL
Edition
1.0 IPS Adjustment for Various Hea d Types on the Module
<H12L head>
FK-9F50-74-0E 8-7 FUJI CORPORATION
Adjusting the camera instllation position
1. Startup Equipment Check to supply power to the head. Startup MotionAdjustmentTool
and move the R-axis and Q-axis to their original positions. (Refer to Section 4.2, step 6
to 9.)
2. Hold down the lower but ton to enter "AD J MODE".
3. Press the lower but t on t o enter "ADJ US TMENT 1" and blin k the LED.
Adjust the camera installation position in the order of pitch, height direction and X
direction.
4. Loosen the f our prism mounting bolts and move the prism back and forth to adjust the
pitch.
R-axis origi nal position
0
～
60000 pulses
Q-axis original positio n.
30000 ± 500 pulses
2G
15
1
CONFIDENTIAL
Edition
1.0 IPS Adjustment for Various Hea d Types on the Module
<H12L head>
FK-9F50-74-0E 8-8 FUJI CORPORATION
5. Loosen the two bolts shown in red cir cles be low, move the bracket back and forth and
adjust the hei ght direction so that t he i mag e of the jig fits into the green fra me.
6. Loosen the two bolts shown in red circles below, and move the bracket l ef t an d right to
adjust the X direction so t hat t he image of the ji g f its into t he gr een frame.
Misalignment in the
height dire ct ion
Misalig nment i n the
X-direction
