Edition
1.0 IPS Adjustment for Various Hea d Types on the Module
<H12L head>
FK-9F50-74-0E 8-7 FUJI CORPORATION
Adjusting the camera instllation position
1. Startup Equipment Check to supply power to the head. Startup MotionAdjustmentTool
and move the R-axis and Q-axis to their original positions. (Refer to Section 4.2, step 6
to 9.)
2. Hold down the lower but ton to enter "AD J MODE".
3. Press the lower but t on t o enter "ADJ US TMENT 1" and blin k the LED.
Adjust the camera installation position in the order of pitch, height direction and X
direction.
4. Loosen the f our prism mounting bolts and move the prism back and forth to adjust the
pitch.
R-axis origi nal position
0
～
60000 pulses
Q-axis original positio n.
30000 ± 500 pulses
2G
15
1
CONFIDENTIAL
Edition
1.0 IPS Adjustment for Various Hea d Types on the Module
<H12L head>
FK-9F50-74-0E 8-8 FUJI CORPORATION
5. Loosen the two bolts shown in red cir cles be low, move the bracket back and forth and
adjust the hei ght direction so that t he i mag e of the jig fits into the green fra me.
6. Loosen the two bolts shown in red circles below, and move the bracket l ef t an d right to
adjust the X direction so t hat t he image of the ji g f its into t he gr een frame.
Misalignment in the
height dire ct ion
Misalig nment i n the
X-direction
CONFIDENTIAL
Edition
1.0 IPS Adjustment for Various Hea d Types on the Module
<H12L head>
FK-9F50-74-0E 8-9 FUJI CORPORATION
7. Confir m that t he center value, r esolution a nd tilt are wit hin tolerance.
8. Press the low er but t on t o save t he s et t ing.
9. Remov e t he jig nozzle.
Inspection item
Tolerance
Camera resolution ch eck
L: X = 90
～
110
L: Z = 90
～
110
Center val ue
R: Xs = 390±25 Zp = 320 ± 10
L: XE = 90±20
Zp = 320±20
Tilt
R: dX = 0
～
9
（
Target : 0
）
, dZ = 0
～
9 (Target: 0)
L: dX = 0
～
9
（
Target : 0
）
, dZ = 0
～
9 ( Target : 0)
Resolution
Center val ue
Tilt
