Edition
1.0 IPS Adjustment for Various Head Types on the Module
<DX head>
FK-9F50-74-0E 3-9 FUJI CORPORATION
23. To increase the current value, push the lower button.
24. To decrease the curr ent v alue, push the upper button to select “ DOWN”, and then push
the lower but t on to decr ease the v alue.
25. If you need to adjust t he GR and GL values separate ly, hold down the lower button with
either “UP” or “DOWN” selected to move the asterisk (*) symbol to L or R. The left and
right value s can now be a djust ed separat ely.
26. Once the gray values are close to the target value, use the upper button
to select “BACK”.
27. Push the lower b ut t on
once to display “ CU R RENT”.
Left value can be
adjusted separately
Right value can be
adjusted separately
BACK
CURRENT
CONFIDENTIAL
Edition
1.0 IPS Adjustment for Various Head Types on the Module
<DX head>
FK-9F50-74-0E 3-10 FUJI CORPORATION
28. Push the upper butt on once to disp lay “SET”.
29. Push the lower button
once to sav e t he settings.
30. Push the upper butt on
once to select “ AD JUSTME NT 3”.
SET
ADJUSTMENT 3
CONFIDENTIAL
Edition
1.0 IPS Adjustment for Various Head Types on the Module
<DX head>
FK-9F50-74-0E 3-11 FUJI CORPORATION
31. Push the lower b ut t on once to display “CHE CK”.
32. Block the left-hand glass w ith a piece of paper as shown be low.
33. With the glass still blocked, push the lower button
.
34. Check that “EDGE2_OK” and “EDGE3_NG” are displayed. Also, check that “S2=0%”
and “S3=100%” are displayed.
Block with
paper
CHECK
