Edition 1.0 IPS Adjustment for Various Head Types on the Module
<V12 head>
FK-9F50-74-0E
4-11
FUJI CORPORATION
5. Press the upper button t o disp lay “CU RRENT BACK”.
6. Press the low er but t on t o return to “ADJUST M ENT2 CURRENT”.
7. Press the upper button to display “ADJUSTMENT2 SET” and then press the lower
button to save the sett ings.
Tolerance
Target value
GR, GL (Gray value)
95~250
120
CURRENT
24mA or l ess
Same as tolerance
CONFIDENTIAL
Edition 1.0 IPS Adjustment for Various Head Types on the Module
<V12 head>
FK-9F50-74-0E
4-12
FUJI CORPORATION
Adjust i ng t he current value (grayscale value) for IPS version 1.21 and above
It is possible to adjust t he R C U R RE NT a nd L CURRENT separately.
1. Press the lower button once, and t hen w it h [CURR ENT UP] or [C URRENT DOWN]
displayed, press and hold the lower but t on for 2 to 3 seconds .
2. An asterisk mar k * d isplays next t o the R CURRE NT value only. The lower but ton
can now be used t o adjust t he R C U RRENT value.
3. Press and hold the lower but ton for 2 to 3 seconds. An asterisk mark * d isplays next
to the L CURRENT value only. The lower but t on can now be used to adjust the R
CURRENT value.
CONFIDENTIAL
Edition 1.0 IPS Adjustment for Various Head Types on the Module
<V12 head>
FK-9F50-74-0E
4-13
FUJI CORPORATION
4. Press and hold the lower but ton for 2 to 3 seconds. An asterisk mark * d isplays next
to both the R CURRENT and L CURRENT values. The l ower button can now be
used to adjust t he R CUR RE NT and L CURRENT values toget her. O nce the values
are within to lerance, press t he upper button once with [BACK] selected to r et ur n t o
the [CURRENT] screen. Pr ess t he upper butt on once to select [S ET] and then
press the low er but ton once to save the v alues.
5. Use the upper but t on t o r eturn to [ADJ MODE] and t hen r eboot the m achine to t ur n
the head pow er O FF and return to [AUTO MODE].
