u Attaching warning signs:
If a machine can be locked, it must be.
However, there are situations where energy isolating devices cannot accom-
modate locks. In these cases, the energy isolating devices must be tagged to
warn employees that the machine is de-energized for servicing. The tag or
label must be securely fastened, it must be placed in a position visible to all
and it may only be removed by the person who attached it.
u Release of stored energy:
Stored energy in the compressed air supply or electrical energy in electrolytic
capacitors must be released by appropriate means.
After switching off the machine, wait until the voltages and the compressed air
have discharged, so that work can be performed without any risk.
u Testing the lock out:
The lock can be easily tested by pressing the START button.
The following steps must be taken to restore the machine to operation.
u Check the working area. Authorized employees should remove all of their tools
and reinstall all safety features.
u Notify all affected employees.
u Before removing even one lock or tag, inform all workers in the affected area
that the machine is going to be restarted.
u Remove all locks/tags.
Every authorized employee must remove his own lock and shut it away.
u Turn the machine on. Make sure that authorized staff check the equipment in
operation to ensure that repairs were performed correctly
Testing
Service personnel may test circuits by energizing them briefly without suspending
the Lock Out / Tag Out Procedure. This may only be done when no other work is
being performed by any other person on the equipment being tested.
It is extremely important that all remote START switches be tagged with the "Do
Not Operate" tag to prevent inadvertent operation of the equipment during these
periods.
Responsibilities
• It shall be the responsibility of the maintenance and service personnel to make
sure this procedure is adhered to.
• It shall be the responsibility of the maintenance and service personnel's imme-
diate supervisor to instruct his personnel on this procedure.
• It shall be the responsibility of the Safety Officer with assistance from the
Safety Committee, Health Service Department, and the various managers and
vice-presidents to administer the Lock Out / Tag Out Procedure.
www.asm-smt.com
Equipment required for Workflow 3 Maintenance TX V2
Tools Wear parts
T01 none Vacuum cleaner W02 Nozzle magazine with ceramic nozzles 2xxx/28xx
T02 none Waste bin for nozzles W16 03070280-xx Nozzle type 2057 cpl. / TPU
T03 00377393-xx Anti-static tweezers, Bernstein 5-192 W20 03050213-xx Filter element 5um
T05 03010565-xx Calibration part version 3 W21 03003717-xx Filter element
T07 03078400-xx Torque Screwdriver ESD 1,0-5,0 Nm W31 03070370-xx Vacuum filter F10
T08 03078706-xx Bitholder f. Screwdriver TorqueVario W58 Nozzle magazine with nozzles 4xxx/6xxx
T09 03073256-xx Extension/ straight TX20 Consumables
T18 00378524-xx Scissors C03 03082092-xx Cleaning Wipe, KM-Wipe
T20 none Flashlight C04 00315253-xx SIPLACE cleaning-tissue
T31 00376492-xx Hexagon ball-point screwdriver set C19 none Compressed Air
T34 00378523-xx Craft brush C26 03020782-xx Interflon Fin Grease (Aerosol)
T56 none Grease container for Interflon C28 00388802S01 SM Role labels 9x5 black flat
T58 03067130-xx Transport Box CPP C31 00372972-xx Protective gloves latex
T62 03112729-xx Protective cover CO sensor C&P20P C49 03121952-xx Grease cartridge BEM 34-132,400g
T89 03123777-xx One-handed grease gun cpl.f.400ml cartr.
T90 Spanner Size 15
