15 WF 3 TX-Series Maintenance Switch on the machine and return the tables (COT) 6 min 1 / 1 C A U T I O N ! R e f e r t o s a f e t y i n s t r u c t i o n s i n u s e r m a n u a l b e f o r e c o m m e n c i n g M a …
www.asm-smt.com
15 WF 3 TX-Series Maintenance Switch on the machine and return the tables (COT) 6 min 1 / 1
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status ON Conveyor Empty
NOTICE! ESD guidelines are to be followed Tool: Wear Part: Consumables:
www.asm-smt.com
1 Switch on the machine. 2 Return the COT at location 2. 3 Close the cover at location 2.
4 Press the insert COT button to dock the
table.
5 Repeat steps 2 to 4 for the other location. 6 Do not press the start button.
